Datasheet

New Product
MSP5.0A
Vishay General Semiconductor
www.vishay.com For technical questions within your region, please contact one of the following:
[e-mail]
, [e-mail], [e-mail]
Document Number: 88487
Revision: 16-Jun-09
2
Notes
(1)
Pulse test: t
p
≤ 50 ms
(2)
Surge current waveform per Fig. 1 and derate per Fig. 2
Note
(1)
Thermal resistance from junction to ambient and junction to lead mounted on P.C.B. with 6.0 mm x 6.0 mm copper pad areas. R
θJL
is measured
at the terminal of cathode band.
Notes
(1)
Immunity to IEC-61000-4-2 air discharge mode has a typical performance > 30 kV
(2)
System ESD standard
Note
(1)
Automotive grade
ELECTRICAL CHARACTERISTICS (T
A
= 25 °C unless otherwise noted)
DEVICE
TYPE
DEVICE
MARKING
CODE
BREAKDOWN
VOLTAGE
V
BR
AT I
T
(1)
(V)
TEST
CURRENT
I
T
(mA)
STAND-OFF
VOLTAGE
V
WM
(V)
MAXIMUM
REVERSE
LEAKAGE
AT V
WM
I
D
(µA)
MAXIMUM
CLAMPING
VOLTAGE
(2)
V
C
(V) AT I
PPM
(A)
10/1000 µs
MAXIMUM
CLAMPING
VOLTAGE
(2)
V
C
(V) AT I
PPM
(A)
8/20 µs
MIN. MAX.
MSP5.0A AE 6.40 7.07 10 5.0 100 9.2 10.9 14.5 57
THERMAL CHARACTERISTICS (T
A
= 25 °C unless otherwise noted)
PARAMETER SYMBOL VALUE UNIT
Typical thermal resistance
(1)
R
θJA
R
θJL
125
30
°C/W
IMMUNITY TO STATIC ELECTRICAL DISCHARGE TO THE FOLLOWING STANDARDS
(T
A
= 25 °C unless otherwise noted)
STANDARD TEST TYPE TEST CONDITIONS SYMBOL CLASS VALUE
AEC-Q101-001 Human body model (contact mode) C = 100 pF, R = 1.5 kΩ
V
C
H3B > 8 kV
IEC-61000-4-2
(2)
Human body model (air discharge mode)
(1)
C = 150 pF, R = 150 Ω 4 > 15 kV
ORDERING INFORMATION (Example)
PREFERRED P/N UNIT WEIGHT (g) PREFERRED PACKAGE CODE BASE QUANTITY DELIVERY MODE
MSP5.0A-E3/89A 0.006 89A 4500 7" diameter plastic tape and reel
MSP5.0AHE3/89A
(1)
0.006 89A 4500 7" diameter plastic tape and reel
MSP5.0A-M3/89A 0.006 89A 4500 7" diameter plastic tape and reel
MSP5.0AHM3/89A
(1)
0.006 89A 4500 7" diameter plastic tape and reel
