Datasheet

K3020P(G) Series
Vishay Telefunken
www.vishay.de • FaxBack [phone]
4 (9)
Document Number 83505
Rev. A5, 13–Sep–99
I
F
y I
FT
95 10814
dv/dt
cr
Highest value of the “rate of rise of off-state voltage” which does not cause any switching from the
off-state to the on-state
dv/dt
crq
Highest value of the “rate of rise of communicating voltage” which does not switch on the device again,
after the voltage has decreased to zero and the trigger current is switched from I
FT
to zero
I
F
= 0
dv / dt
crq
dv / dt
cr
Figure 2.
M
95 10815
270 Ω
TTL
+5 V
0.1 µF
VAC ~
Galvanical separation
Figure 3. Motor control circuit
