Electrical Characteristics (T
amb
= 25°C)
Input (Emitter)
Parameter Test Conditions Symbol Min. Typ. Max. Unit
Forward voltage I
F
= 50 mA V
F
1.25 1.6 V
Junction capacitance V
R
= 0, f = 1 MHz C
j
50 pF
Output (Detector)
Parameter Test Conditions Symbol Min. Typ. Max. Unit
Forward peak off-state
voltage (repetitive)
I
DRM
= 100 nA V
DRM
1)
400 V
Peak on-state voltage I
TM
= 100 mA V
TM
1.5 3 V
Critical rate of rise of I
FT
= 0, I
FT
= 30 mA (dv/dt)
cr
10 V/ m s
off-state voltage
FT FT
(dv/dt)
crq
0.1 0.2 V/ m s
1)
Test voltage must be applied within dv/dt ratings
Coupler
Parameter Test Conditions Type Symbol Min. Typ. Max. Unit
Emitting diode trigger V
S
= 3 V, R
L
= 150 W K3020P(G) I
FT
15 30 mA
ggg
current
S L
K3021P(G) I
FT
8 15 mA
K3022P(G) I
FT
5 10 mA
K3023P(G) I
FT
2 5 mA
Holding current I
F
= 10 mA, V
S
≥ 3 V I
H
100 m A
Note: I
FT
is defined as a minimum trigger current
V~
R
S
95 10813
Test condition:
dv/dt
cr
V
S
= 2/3 V
DRM
(Sine wave)
R
L
= 33 kΩ
dv/dt
crq
V
eff
= 30 V
(Sine wave)
R
L
= 2 kΩ
I
FT
R
L
Figure 1. Test circuit for dv/dt
cr
and dv/dt
crp
