Datasheet

K3020P(G) Series
Vishay Telefunken
www.vishay.de • FaxBack [phone]
2 (9)
Document Number 83505
Rev. A5, 13–Sep–99
Features
Approvals:
D BSI: BS EN 41003, BS EN 60095 (BS 415),
BS EN 60950 (BS 7002),
Certificate number 7081 and 7402
D FIMKO (SETI): EN 60950,
Certificate number 12398
D Underwriters Laboratory (UL) 1577 recognized,
file number E-76222
D VDE 0884, Certificate number 94778
VDE 0884 related features:
D Rated impulse voltage (transient overvoltage)
V
IOTM
= 6 kV peak
D Isolation test voltage
(partial discharge test voltage) V
pd
= 1.6 kV
D Rated isolation voltage (RMS includes DC)
V
IOWM
= 600 V
RMS
(848 V peak)
D Rated recurring peak voltage (repetitive)
V
IORM
= 600 V
RMS
D Creepage current resistance according to
VDE 0303/IEC 112
Comparative Tracking Index: CTI = 275
D Thickness through insulation ≥ 0.75 mm
General features:
D Isolation materials according to UL 94-VO
D Pollution degree 2 (DIN/VDE 0110 resp. IEC 664)
D Climatic classification 55/100/21 (IEC 68 part 1)
D Special construction:
Therefore, extra low coupling capacity of
typical 0.2 pF, high Common Mode Rejection
D I
FT
offered into 4 groups
D Coupling System C
Absolute Maximum Ratings
Input (Emitter)
Parameter Test Conditions Symbol Value Unit
Reverse voltage V
R
5 V
Forward current I
F
80 mA
Forward surge current t
p
≤ 10 m s I
FSM
3 A
Power dissipation T
amb
≤ 25 ° C P
V
100 mW
Junction temperature T
j
100 ° C
Output (Detector)
Parameter Test Conditions Symbol Value Unit
Off state output terminal voltage V
DRM
400 V
On state RMS current I
TRMS
100 mA
Peak surge current, non-repetitive t
p
≤ 10 ms I
TMS
1.5 A
Power dissipation T
amb
≤ 25 ° C P
V
300 mW
Junction temperature T
j
100 ° C
Coupler
Parameter Test Conditions Symbol Value Unit
Isolation test voltage (RMS) V
IO
1)
3.75 kV
Total power dissipation T
amb
≤ 25 ° C P
tot
350 mW
Ambient temperature range T
amb
–40 to +85 ° C
Storage temperature range T
stg
–55 to +100 ° C
Soldering temperature 2 mm from case, t ≤ 10 s T
sd
260 ° C
1)
Related to standard climate 23/50 DIN 50014
