VISHAY
ILD1/ 2/ 5 / ILQ1/ 2/ 5
Document Number 83646
Rev. 1.3, 10-Jun-04
Vishay Semiconductors
www.vishay.com
7
Package Dimensions in Inches (mm)
Figure 11. Collector-Emitter Leakage Current vs.Temp.
iild1_11
100806040200-20
10
10
10
10
10
10
10
10
-2
-1
0
1
2
3
4
5
T
A
- Ambient Temperature - °C
I
CEO
- Collector-Emitter - nA
Vce=10V
Typical
Figure 12. Propagation Delay vs. Collector Load Resistor
iild1_12
R
L
- Collector Load Resistor - kΩ
100101.1
1
10
100
1000
1.0
1.5
2.0
2.5
tpLH
tpHL
t
pLH
- Propagation Low-High µs
t
pHL
- Propagation High-Low µs
Ta = 25°C, IF = 10 mA
Vcc=5V,Vth=1.5V
i178006
pin one ID
.255 (6.48)
.268 (6.81)
.379 (9.63)
.390 (9.91)
.030 (0.76)
.045 (1.14)
4° typ.
.100 (2.54) typ.
10°
3°–9°
.300 (7.62)
typ.
.018 (.46)
.022 (.56)
.008 (.20)
.012 (.30)
.110 (2.79)
.130 (3.30)
.130 (3.30)
.150 (3.81)
.020 (.51 )
.035 (.89 )
.230(5.84)
.250(6.35)
4
3
2
1
.031 (0.79)
.050 (1.27)
5
6
78
ISO Method A
