ILD1/ 2/ 5 / ILQ1/ 2/ 5
Vishay Semiconductors
Switching Non-saturated
Switching Saturated
Common Mode Transient Immunity
Parameter Current Delay Rise time Storage Fall time Propagation
H-L
Propagation
L-H
Test condition V
CE
= 5.0 V, R
L
= 75 Ω, 50 % of V
PP
Symbol I
F
t
D
t
r
t
S
t
f
t
PHL
t
PLH
Unit mA µs µs µs µs µs µs
ILD1
ILQ1
20 0.8 1.9 0.2 1.4 0.7 1.4
ILD2
ILQ2
5.0 1.7 2.6 0.4 2.2 1.2 2.3
ILD5
ILQ5
10 1.7 2.6 0.4 2.2 1.1 2.5
Parameter Current Delay Rise time Storage Fall time Propagation
H-L
Propagation
L-H
Test condition V
CE
= 0.4 V, R
L
= 1.0 kΩ, V
CC
= 5.0 V, V
TH
= 1.5 V
Symbol I
F
t
D
t
r
t
S
t
f
t
PHL
t
PLH
Unit mA µs µs µs µs µs µs
ILD1
ILQ1
20 0.8 1.2 7.4 7.6 1.6 8.6
ILD2
ILQ2
5.0 1.0 2.0 5.4 13.5 5.4 7.4
ILD5
ILQ5
10 1.7 7.0 4.6 20 2.6 7.2
Parameter Test condition Symbol Min Ty p. Max Unit
Common mode rejection,
output high
V
CM
= 50 V
P-P
, R
L
= 1.0 kΩ,
I
F
= 0 mA
CM
H
5000 V/µs
Common mode rejection,
output low
V
CM
= 50 V
P-P
, R
L
= 1.0 kΩ,
I
F
= 10 mA
CM
L
5000 V/µs
Common mode coupling
capacitance
C
CM
0.01 pF
