ICTE5 thru ICTE18C, 1N6373 thru 1N6386
www.vishay.com
Vishay General Semiconductor
Revision: 18-Sep-12
4
Document Number: 88356
For technical questions within your region: [e-mail]
, [e-mail], [e-mail]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
Fig. 7 - Typical Characteristics Clamping Voltage Fig. 8 - Power Derating Curve
PACKAGE OUTLINE DIMENSIONS in inches (millimeters)
V
C
- Clamping Voltage (V)
I
PP
- Peak Pulse Current (A)
10
50
1
10861214161820222426
28
Uni-Directional Only
T
A
= 25 °C
ICTE5 ICTE8 ICTE10 ICTE12 ICTE18
ICTE15
8.0
7.0
6.0
5.0
4.0
3.0
2.0
1.0
0
0 25 50 75 100 125 150 175 200
P
D
- Power Dissipation (W)
T
L
- Lead Temperature (°C)
L = 0.375" (9.5 mm)
Lead Lengths
1.0 (25.4)
MIN.
1.0 (25.4)
MIN.
0.375 (9.5)
0.285 (7.2)
0.210 (5.3)
0.190 (4.8)
DIA.
0.042 (1.07)
0.038 (0.96)
DIA.
Case Style 1.5KE
