ICTE5 thru ICTE18C, 1N6373 thru 1N6386
www.vishay.com
Vishay General Semiconductor
Revision: 18-Sep-12
2
Document Number: 88356
For technical questions within your region: [e-mail]
, [e-mail], [e-mail]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
Notes
(1)
“C” suffix indicates bi-directional
(2)
ICTE5 and 1N6373 are not available as bi-directional
(3)
Clamping factor: 1.33 at full rated power; 1.20 at 50 % rated power; clamping factor: the ratio of the actual V
C
(clamping voltage) to the V
BR
(breakdown voltage) as measured on a specific device
Note
(1)
AEC-Q101 qualified
ELECTRICAL CHARACTERISTICS (JEDEC REGISTERED DATA) (T
A
= 25 °C unless otherwise noted)
JEDEC
TYPE
NUMBER
GENERAL
SEMICONDUCTOR
PART NUMBER
STAND-OFF
VOLTAGE
V
WM
(V)
MINIMUM
BREAKDOWN
VOLTAGE
AT 1.0 mA
V
BR
(V)
MAXIMUM
REVERSE
LEAKAGE
AT V
WM
I
D
(μA)
MAXIMUM
CLAMPING
VOLTAGE
AT I
PP
= 1.0 A
V
C
(V)
MAXIMUM
CLAMPING
VOLTAGE AT
I
PP
= 10 A
V
C
(V)
MAXIMUM
PEAK
PULSE
CURRENT
I
PP
(A)
UNI-DIRECTIONAL TYPES
1N6373
(2)
ICTE5
(2)
5.0 6.0 300 7.1 7.5 160
1N6374 ICTE8 8.0 9.4 25.0 11.3 11.5 100
1N6375 ICTE10 10.0 11.7 2.0 13.7 14.1 90
1N6376 ICTE12 12.0 14.1 2.0 16.1 16.5 70
1N6377 ICTE15 15.0 17.6 2.0 20.1 20.6 60
1N6378 ICTE18 18.0 21.2 2.0 24.2 25.2 50
BI-DIRECTIONAL TYPES
1N6382 ICTE8C 8.0 9.4 50 11.4 11.6 100
1N6383 ICTE10C 10.0 11.7 2.0 14.1 14.5 90
1N6384 ICTE12C 12.0 14.1 2.0 16.7 17.1 70
1N6385 ICTE15C 15.0 17.6 2.0 20.8 21.4 60
1N6386 ICTE18C 18.0 21.2 2.0 24.8 25.5 50
ORDERING INFORMATION (Example)
PREFERRED P/N UNIT WEIGHT (g) PREFERRED PACKAGE CODE BASE QUANTITY DELIVERY MODE
ICTE5-E3/54 0.968 54 1400 13" diameter paper tape and reel
ICTE5HE3/54
(1)
0.968 54 1400 13" diameter paper tape and reel
