MOUNTING
The trimmer can be mounted on printed-circuit boards with a grid of 2.50 mm or 2.54 mm and a minimum hole diameter of
1.25 mm.
PACKAGING
Bulk packaged in cardboard boxes lined with expanded plastic. For smallest packaging quantity (SPQ) see “Electrical Data”
table.
ORDERING INFORMATION
C
min.
/ C
max.
(pF)
CATALOG NUMBER BFC2 808 .....
VERTICAL VERSION HORIZONTAL VERSION
ROUND HEAD ROUND HEAD
TOP AND BOTTOM ADJUSTMENT TOP ADJUSTMENT ONLY TOP AND BOTTOM ADJUSTMENT
1.4 / 5.5 11558 00004 51558
2 / 9 00018 - -
2 / 10 11109 00005 51109
2 / 10 - 11004 -
2 / 15 11159 - -
2 / 18 00016 - -
2.5 / 20 - 11006 -
2.5 / 22 11229 00006 51229
3 / 33 11339 - -
ELECTRICAL DATA
GUARANTEED
MAX. C
min.
/
MIN. C
max.
AT 200 kHz
(pF)
SPINDLE
SHAPE
OF
HEAD
ADJ.
MODE
DIEL.
tan 
AT C
max.
x 10
-4
TEMP.
COEFF.
(10
-6
/K)
MIN. f
res
AT C
max.
(MHz)
COL.
OF
BASE
SPQ
CATALOG
NUMBER
BFC2 ... .....
1 MHz 100 MHz
1.4 / 5.5
Vertical Round
Top + bottom
PE  10  25 -250 ± 350 850 Grey
1400 ....80811558
Top 1400 ....80800004
Horizontal Round Top + bottom 1200 ....80851558
2 / 9 Vertical Round Top + bottom PTFE  10  15 -150 ± 800 400 Yellow 1400 ....80800018
2 / 10
Vertical Round
Top + bottom
PP  10  25 -250 ± 800 480 Yellow
1400 ....80811109
Top 1400 ....80800005
Horizontal Round Top + bottom 1200 ....80851109
2 / 15 Vertical Round Top + bottom PP  10  25 -250 ± 600 450 Blue 1400 ....80811159
2 / 18 Vertical Round Top + bottom PTFE  10  15 -250 ± 350 350 Green 1400 ....80800016
2.5 / 20 Vertical Round Top PET  160 - 0 ± 1100 250 Green 1000 ....80811006
2.5 / 22
Vertical Round
Top + bottom
PP  10  25 -200 ± 500 350 Green
1400 ....80811229
Top 1400 ....80800006
Horizontal Round Top + bottom 1200 ....80851229
3 / 33 Vertical Round Top + bottom PP  10 - -250 ± 350 300 Brown 1400 ....80811339
