8EWF..S QUIET IR Series
I
F(AV)
Max. Average Forward Current 8 A @ T
C
= 96° C, 180° conduction half sine wave
I
FSM
Max. Peak One Cycle Non-Repetitive 170 10ms Sine pulse, rated V
RRM
applied
Surge Current 200 10ms Sine pulse, no voltage reapplied
I
2
t Max. I
2
t for fusing 140 10ms Sine pulse, rated V
RRM
applied
200 10ms Sine pulse, no voltage reapplied
I
2
√t Max. I
2
√t for fusing 2000 A
2
√s t = 0.1 to 10ms, no voltage reapplied
Voltage Ratings
Part Number
V
RRM
, maximum V
RSM
, maximum non repetitive I
RRM
peak reverse voltage peak reverse voltage 150°C
VVmA
8EWF02S 200 300 3
8EWF04S 400 500
8EWF06S 600 700
Absolute Maximum Ratings
Parameters 8EWF..S Units Conditions
t
rr
Reverse Recovery Time 140 ns I
F
@ 8Apk
I
rr
Reverse Recovery Current 2.6 A @ 25A/µs
Q
rr
Reverse Recovery Charge 0.25 µC @ T
J
= 25°C
S Snap Factor tb/ta 0.5 -
Parameters 8EWF..S Units
Conditions
A
A
2
s
V
FM
Max. Forward Voltage Drop 1.2 V @ 8A, T
J
= 25°C
r
t
Forward slope resistance 16 mΩ
V
F(TO)
Threshold voltage 1.13 V
I
RM
Max. Reverse Leakage Current 0.1 T
J
= 25 °C
3T
J
= 150 °C
Electrical Specifications
Parameters 8EWF..S Units Conditions
T
J
= 150°C
V
R
= rated V
RRM
mA
Typical Reverse Recovery Characteristics
t
I
FM
t
rr
Q
rr
I
rr
di
dt
tbta
