Vishay BCcomponents
Aluminum Capacitors
Radial Miniature Long Life
Note
1. Unless otherwise specified, all electrical values in Table 2 apply
at T
amb
=20°C, P = 86 to 106 kPa, RH = 45 to 75%.
ORDERING EXAMPLE*
Electrolytic capacitor 048 series
2200 μF/16 V; ±20%
Nominal case size: ∅12.5 × 25 mm; Form TFA
Catalog number: 2222 048 35222.
* To ensure delivery of lead (Pb)-free parts during the
transition period, please contact your Vishay sales agent.
ELECTRICAL DATA
SYMBOL DESCRIPTION
C
R
rated capacitance at 100 Hz, tolerance ±20%
I
R
rated RMS ripple current at 100 Hz, 105 °C
I
L1
max. leakage current after 1 minute at U
R
Tan δ max. dissipation factor at 100 Hz
Z max. impedance at 100 kHz
Table 2
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(μF)
NOMINAL
CASE SIZE
∅D × L
(mm)
I
R
100 Hz
105 °C
(mA)
I
L1
1min
(μA)
Tan δ
100 Hz
Z
100 kHz
(mΩ)
CATALOG NUMBER 2222 048 .....
BULK PACKAGING TAPED
FORM CA FORM CB FORM TFA
6.3
6800 16 × 25 1350 430 0.32 56 53682 63682 33682
10000 16 × 35 1700 630 0.40 42 53103 63103 −
10
1000 10 × 16 470 100 0.19 180 54102 64102 34102
2200 12.5 × 20 800 220 0.21 90 54222 64222 34222
3300 12.5 × 25 1000 330 0.23 68 54332 64332 34332
4700 16 × 25 1270 470 0.25 56 54472 64472 34472
6800 16 × 31 1550 680 0.29 45 54682 64682 34682
10000 18 × 35 1870 1000 0.37 36 54103 64103 −
16
470 10 × 12 360 78 0.16 250 55471 65471 35471
1000 10 × 20 600 160 0.16 140 55102 65102 35102
2200 12.5 × 25 1000 360 0.18 70 55222 65222 35222
3300 16 × 25 1220 530 0.20 56 55332 65332 35332
4700 16 × 31 1500 760 0.22 45 55472 65472 35472
6800 16 × 35 1690 1100 0.26 42 55682 65682 −
10000 18 × 35 1980 1600 0.34 34 55103 65103 −
25
470 10 × 16 440 120 0.14 180 56471 66471 36471
1000 12.5 × 20 720 250 0.14 100 56102 66102 36102
2200 16 × 25 1120 550 0.16 56 56222 66222 36222
3300 16 × 31 1450 830 0.18 45 56332 66332 36332
4700 18 × 35 1720 1200 0.20 36 56472 66472 −
35
220 10 × 12 310 80 0.12 280 50221 60221 30221
470 10 × 20 500 170 0.12 150 50471 60471 30471
1000 12.5 × 25 900 350 0.12 75 50102 60102 30102
2200 16 × 31 1340 770 0.14 45 50222 60222 30222
3300 18 × 35 1600 1200 0.16 36 50332 60332 −
4700 18 × 35 1950 1600 0.18 34 50472 60472 −
40
2200 16 × 35 1500 880 0.13 45 57222 67222 −
3300 18 × 35 1600 1300 0.15 36 57332 67332 −
50
220 10 × 16 340 110 0.10 250 51221 61221 31221
470 12.5 × 20 620 240 0.10 110 51471 61471 31471
1000 16 × 25 1030 500 0.10 60 51102 61102 31102
2200 18 × 35 1500 1100 0.12 50 51222 61222 −
3300 18 × 35 1900 1700 0.14 40 51332 61332 −
63
100 10 × 12 240 66 0.09 310 58101 68101 38101
220 10 × 20 400 140 0.09 200 58221 68221 38221
330 12.5 × 20 550 210 0.09 120 58331 68331 38331
470 12.5 × 25 700 300 0.09 80 58471 68471 38471
1000 16 × 31 1150 630 0.09 49 58102 68102 38102
2200 18 × 35 1600 1400 0.11 45 58222 68222 −
