SCHOTTKY RECTIFIER 12 Amp

12CTQ...

12CTQ...S

12CTQ... -1

www.irf.com 1

Bulletin PD-20554 rev. B 07/01

Major Ratings and Characteristics

F(AV)

Rectangular 12 A

waveform

RRM

range 35 to 45 V

FSM

@ tp = 5 µs sine 690 A

6 Apk, T

= 125°C 0.53 V

(per leg)

range - 55 to 175 °C

Characteristics 12CTQ Units

Description/ Features

The 12CTQ center tap Schottky rectifier series has been

optimized for low reverse leakage at high temperature. The

proprietary barrier technology allows for reliable operation up

to 175° C junction temperature. Typical applications are in

switching power supplies, converters, free-wheeling diodes,

and reverse battery protection.

175° C T

operation

Center tap TO-220 package

Low forward voltage drop

High purity, high temperature epoxy encapsulation for

enhanced mechanical strength and moisture resistance

High frequency operation

Guard ring for enhanced ruggedness and long term

reliability

Case Styles

12CTQ... 12CTQ... S 12CTQ... -1

TO-220 D

PAK

F(AV)

= 12Amp

= 35 to 45V

Anode

Base

Common

Cathode

node

Common

Cathode

TO-262

Anode

Base

Common

Cathode

node

Common

Cathode

Anode

Base

Common

Cathode

node

Common

Cathode

Summary of content (8 pages)

PAGE 1
Bulletin PD-20554 rev. B 07/01 12CTQ... 12CTQ...S 12CTQ... -1 SCHOTTKY RECTIFIER 12 Amp IF(AV) = 12Amp VR = 35 to 45V Major Ratings and Characteristics Description/ Features The 12CTQ center tap Schottky rectifier series has been optimized for low reverse leakage at high temperature. The proprietary barrier technology allows for reliable operation up to 175° C junction temperature. Typical applications are in switching power supplies, converters, free-wheeling diodes, and reverse battery protection.
PAGE 2
12CTQ... Series Bulletin PD-20554 rev. B 07/01 Voltage Ratings Part number VR 12CTQ035 12CTQ040 12CTQ045 35 40 45 Max. DC Reverse Voltage (V) VRWM Max. Working Peak Reverse Voltage (V) Absolute Maximum Ratings Parameters IF(AV) Max. Average Forward Current IFSM * See Fig. 5 12CTQ Units (Per Leg) 6 (Per Device) 12 Max. Peak One Cycle Non-Repetitive 690 Surge Current (Per Leg) * See Fig.
PAGE 3
12CTQ... Series Bulletin PD-20554 rev. B 07/01 10 0 100 Rev erse C urre nt - I 150 C 125 C 1 100 C 0.1 75 C 0 .01 50 C 25 C 0.0 01 0 .00 0 1 0 5 10 15 20 25 30 35 40 45 Reverse V olta ge - V R (V ) 10 Fig. 2 - Typical Values Of Reverse Current Vs. Reverse Voltage (Per Leg) 10 0 0 Tj = 25˚C T Tj = 125˚C (p F) Tj = 175˚C Junc tion C apa c itan ce - C Instantaneous Forward Current - IF (A) R (m A ) T J= 175 C 10 T J= 25 C 1 00 1 0.2 0.4 0.6 0.8 1 1.2 1.
PAGE 4
12CTQ... Series Bulletin PD-20554 rev. B 07/01 5 D D D D D 4 .5 Ave ra ge P ow er Loss - (W atts) A llow ab le C a se Tem p e ra ture - ( C ) 17 5 17 0 16 5 DC 16 0 Sq ua re wa ve (D = 0.50) 80% Ra ted V a p p lied R 15 5 4 3 .5 = = = = = 0.20 0.25 0.33 0.50 0.75 3 RM S Lim it 2 .5 DC 2 1 .5 1 0 .5 see note (2) 15 0 0 0 2 4 6 8 10 0 A vera ge Forw ard C urrent - I F(AV) (A ) Fig. 5 - Max. Allowable Case Temperature Vs.
PAGE 5
12CTQ... Series Bulletin PD-20554 rev. B 07/01 Outline Table 10.54 (0.41) MAX. 3.78 (0.15) 3.54 (0.14) 1.32 (0.05) 1.22 (0.05) DIA. 6.48 (0.25) 6.23 (0.24) 2.92 (0.11) 2.54 (0.10) TERM 2 15.24 (0.60) 14.84 (0.58) Base Common Cathode 2 2° 1 2 3 14.09 (0.55) 3.96 (0.16) 13.47 (0.53) 3.55 (0.14) 0.10 (0.004) 1 2.04 (0.080) MAX. Anode 1.40 (0.05) 2 Common Cathode 3 Anode 2.89 (0.11) 1.15 (0.04) 2.64 (0.10) 0.94 (0.04) 0.69 (0.03) 1 2 3 0.61 (0.02) MAX. 4.57 (0.18) 4.32 (0.
PAGE 6
12CTQ... Series Bulletin PD-20554 rev. B 07/01 Outline Table Modified JEDEC outline TO-262 Dimensions in millimeters and (inches) Base Common Cathode 2 1 Anode 2 Common Cathode 3 Anode Marking Information EXAMPLE: THIS IS A 12CTQ040-1 LOT CODE 1789 ASSEMBLED ON WW 19, 1999 IN THE ASSEMBLY LINE "C" INTERNATIONAL RECTIFIER LOGO ASSEMBLY LOT CODE 6 PART NUMBER DATE CODE YEAR 9 = 1999 WEEK 19 LINE C www.irf.
PAGE 7
12CTQ... Series Bulletin PD-20554 rev. B 07/01 Tape & Reel Information TRR 1.60 (0.063) 1.50 (0.059) 4.10 (0.161) 3.90 (0.153) FEED DIR ECTION 1.60 (0.063) 1.50 (0.059) 1.85 (0.073) DIA. 0.368 (0.0145) 0.342 (0.0135) 11.60 (0.457) 1.65 (0.065) 11.40 (0.449) 15.42 (0.609) 15.22 (0.601) TRL 1.75 (0.069) 10.90 (0.429) 1.25 (0.049) 10.70 (0.421) 24.30 (0.957) 23.90 (0.941) DIA. 4.72 (0.186) 16.10 (0.634) 4.52 (0.178) 15.90 (0.626) FEED DIRECTION 13.50 (0.532) 26.40 (1.039) 12.80 (0.504) DIA.
PAGE 8
12CTQ... Series Bulletin PD-20554 rev. B 07/01 Data and specifications subject to change without notice. This product has been designed and qualified for Industrial Level. Qualification Standards can be found on IR's Web site. IR WORLD HEADQUARTERS: 233 Kansas St., El Segundo, California 90245, USA Tel: (310) 252-7105 TAC Fax: (310) 252-7309 Visit us at www.irf.com for sales contact information. 07/01 8 www.irf.
