Installation Tuscany Hoods TVWH360, CTVWH360 TVWH480, CTVWH480
Table of Contents Important Information______________________________________________________________________ 2 Warnings ___________________________________________________________________________________ 3 Dimensions & Specifications _________________________________________________________ 4 Clearance Dimensions _________________________________________________________________5 Interior Ventilator Dimensions __________________________________________________________ 6 Exterior Ventilator Dimensions ______
Warnings WARNING WARNING To reduce the risk of injury to persons in the event of a rangetop grease fire, observe the following. (Based on “Kitchen Firesafety Tips,” published by NFPA.) To reduce the risk of fire, electric shock, or injury to persons, observe the following: • Use this unit only in the manner intended by the manufacturer. If you have any questions, contact the manufacturer.
Dimensions & Specifications 36" W 48" W A 35-7/8" (91.1 cm) 47-7/8" (121.6 cm) 1 (30 2"* .5 cm ) (15 6" .2 cm (4518" .7 cm ) ) A " 24 cm) .0 (61 *NOTE: Optional duct cover sold separately. 18”H. Wall Hoods Description Duct cover width 36” 48” 35-7/8” (91.1 cm) 47-7/8” (121.6 cm) Duct cover depth 12” (30.5 cm) Duct cover height 12” (30.
Clearance Dimensions 12” (30.5 cm) *optional duct cover 18” (45.7 cm) 66” min (167.6 cm) to 72” max (182.9 cm) 30” min (76.2 cm) to 36” max (91.4 cm) 36” (91.
Interior Ventilator Dimensions Top View A 36" W A 17-15/16" (45.6 cm) 36" W B 35-7/8" (91.1 cm) 4-5/8" (11.7 cm) 7" (17.8 cm) dia. duct location B *300 or 600 CFM Interior Ventilator Installation for all Wall Hoods Top View A 36" W 48" W A 17-15/16" (45.6 cm) 23-15/16" (60.8 cm) 36" W 48" W 5-1/2" (14.0 cm) B 35-7/8" (91.1 cm) 47-7/8" (121.6 cm) 10" (25.4 cm) dia.
Exterior Ventilator Dimensions Top View A 36" W 48" W A 17-15/16" (45.6 cm) 23-15/16" (60.8 cm) 36" W 48" W 5-15/16" (15.1 cm) B 35-7/8" (91.1 cm) 47-7/8" (121.6 cm) 10" (25.4 cm) dia. duct location B 900 or 1200 CFM Exterior Ventilator Installation for all Wall Hoods Top View A 36" W 48" W A 17-15/16" (45.6 cm) 23-15/16" (60.8 cm) 36" W 48" W 5-15/16" (15.1 cm) B 35-7/8" (91.1 cm) 47-7/8" (121.6 cm) 10" (25.4 cm) dia.
Planning Information Proper installation of ducting is extremely important to ensure maximum performance from any ventilation product. • All CFMs are based on tests at 0.1 static pressure: without applying static pressure, CFM would be greatly overstated. • Straight runs and gradual turns are best; for example, each 90º elbow is equivalent to 5-10 feet (1.52-3.05 cm) of straight run. • Never use flexible duct; it creates back pressure/air turbulence and greatly reduces performance.
Installation 1 1-1/2” x 3/4” (3.8 cm) x ( 1.9 cm) 1(4.13/1 6 c 6” m) 2 Slot for Wood strip 5/16” Nut driver wood strip Measure down 1-13/16 (4.6 cm) from desired height of hood and secure 1-1/2” x 3/4” wood strip (provided locally) to wall using screws provided. 5/16” Nut driver Use additional mounting screws to secure hood to wood strip. 3 5/16” Nut Driper 5/16” Nut driver CAUTION: Secure vent hood to wall using screws provided. Use additional mounting screws and wall anchors, if necessary.
Duct Cover Option 2 1 Measure distance from ceiling to canopy. Slide the duct cover in place and fasten from inside canopy using the sheet metal screws provided. To install ventillation kit refer to ventillation kit installation instructions.
Service & Registration If service is required, call your authorized service agency. Have the following information readily available. • Model number • Serial number • Date purchased • Name of dealer from whom purchased Clearly describe the problem that you are having.
