Instruction Manual
PM-FCP
Installation Instructions Page 11
Technical Specications
All measurements are in inches (mm).
Securing Pipe to the PM-FCP
Step 1. Secure the 1½” (NPT) pipe to the ceiling plate and tighten by using one (1) M5 x 16 Phillips head screw (supplied)
to the plate.
The M5 x 16 Phillip head screw must be used to stabilize the 1½” (NPT) pipe.
M5 x 16mm
Screw
1-1/2” Pipe
Opening
PM-FCP
