User guide
Table Of Contents
- PJ510_UGTOC.pdf
- PJ510_UG.pdf
- For Your Records
- Features
- Part Names
- Setting Up
- Arrangement
- Adjusting The Projector’s Elevator
- 1 Press and hold in the elevator buttons.
- 2 Raise or lower the projector to the desired height and then release the elevator buttons. When you release the elevator buttons, the elevator feet will lock position.
- 3 As necessary, you can also adjust the height of the projector by twisting the elevator feet by hand.
- Connecting Your Devices
- Connecting Power Supply
- Remote Control
- Power ON/OFF
- Operating
- Multifunctional Settings
- Lamp
- Replacing The Lamp
- 1 Turn off the projector, and unplug the power cord. Allow the lamp bulb to cool for at least 45 minutes.
- 2 Contact your local dealer to prepare a new lamp. Tell the dealer your lamp type number. If the projector is mounted on the ceiling, or if the lamp has broken, also ask the dealer to replace the lamp.
- 3 After making sure that the projector has cooled adequately, slowly flip over the projector, so that the bottom is facing up.
- 4 Hold the release button while sliding out the lamp cover.
- 5 Unscrew the 2 screws, and slowly pick up the lamp by the handles.
- 6 Insert the new lamp, and tighten the 2 screws firmly to lock it in place.
- 7 Slide the lamp cover into place until it locks into position.
- 8 Slowly turn the projector so that the top is facing up.
- 9 Turn on the projector, and reset the lamp timer.
- Replacing The Lamp
- Air Filter
- Caring For The Air Filter
- Replacing The Air Filter
- 1 Turn off the projector, and unplug the power cord.
- 2 Contact your local dealer to prepare a new air filter. Tell the dealer your air filter type number.
- 3 After making sure that the projector has cooled adequately, remove the filter cover. Hold the release buttons of the filter cover, while pulling it up.
- 4 Hold the release buttons of the air filter, while pulling down on it.
- 5 Insert a new air filter, and replace the filter cover.
- 6 Reset the filter timer, according to following “Reset The Filter Timer”.
- Other Care
- Troubleshooting
- Related Messages
- TO MAXIMIZE PERFORMANCE, LAMP REPLACEMENT IS RECOMMENDED.
- The unit does not display a warning message on the screen when the lamp expires or fails. When the lamp does not light, this indicates that the lamp is no longer functional and should be replaced. Replace the lamp and do not forget to reset the timer.
- CLEAN THE AIR FILTER
- AFTER CLEANING AIR FILTER,
- RESET THE FILTER TIMER.
- A note of precaution when cleaning the air filter.
- After cleaning the filter, operate FILTER TIME of the OPTION Menu, then perform reset of the filter timer.
- NO INPUT IS DETECTED
- ON ***
- There is no input signal.
- Check the signal input connection and the status of the signal source.
- SYNC IS OUT OF RANGE
- ON ***
- The horizontal or vertical frequencies of the inputted signal is outside of the operating range limits of this unit. Please confirm the specs for this unit or the signal source specs.
- CHECK THE AIR FLOW
- The internal temperature is rising. Please turn the power OFF, then allow the unit to cool down for approximately 20 minutes. After hav- ing confirmed the following items, then please reset the power to ON.
- . Is there blockage of the air filter?
- . Is the air filter dirty?
- . Does the ambient temperature exceeds 35 C?
- CLEAN THE AIR FILTER
- POWER OFF FIRST, THEN CLEAN THE AIR FILTER. AFTER CLEANING THE AIR FILTER, RESET THE FILTER TIMER.
- A note of precaution when cleaning the air filter.
- Please immediately turn the power off, and clean or change the air filter by referring to the “Air Filter” section of this manual. After you have cleaned or changed the air filter, please be sure to reset the filter timer.
- If the same message is displayed after the treatment, please clean the transparent area of filter cover and the dust-detecting window, according to the following.
- Note:
- 1 Turn off the projector, and unplug the power cord.
- 2 After making sure that the projector has cooled adequately, remove the filter cover. Hold the release buttons of the filter cover, while pulling it up.
- 3 Wipe the transparent area of the filter cover by using a swab or a soft cloth.
- 4 Remove the air filter. Hold the release buttons of the air filter, while pulling it down.
- 5 Wipe the dust-detecting window by using a soft cloth.
- 6 Replace the air filter and filter cover.
- Regarding The Indicator Lamps
- POWER indicator
- LAMP indicator
- TEMP indicator
- Description
- Lighting in orange
- Turned off
- Turned off
- The unit is in a standby state. Please refer to the “Power ON/OFF” section of this manual.
- Flashing in green
- Turned off
- Turned off
- The unit is warming up. Please wait.
- Lighting in green
- Turned off
- Turned off
- The unit is in an ON state. Ordinary operations may be performed.
- Flashing in orange
- Turned off
- Turned off
- The unit is cooling down. Please wait.
- Blinking in red
- -
- -
- The unit is cooling down. A certain error has been detected. Wait until the POWER indicator has finished flashing, and then perform the proper response measure using the item descriptions below as reference.
- Lighting or blinking in red
- Lighting in red
- Turned off
- The projector lamp has not been properly fixed (attached), the projector lamp does not light, and/or there is a possibility that...
- . Is there blockage of the air passage aperture?
- . Is the air filter is dirty?
- . Does the peripheral temperature exceed 35 C?
- Lighting or blinking in red
- Blinking in red
- Turned off
- The lamp cover has not been properly fixed (attached). Turn the power OFF and wait at least 45 minutes. After the unit has suffi...
- POWER indicator
- LAMP indicator
- TEMP indicator
- Description
- Lighting or blanking in red
- Turned off
- Blinking in red
- The cooling fan is not operating. Turn the power OFF and wait at least 20 minutes. After the unit has sufficiently cooled down, please make confirmation of the following item, and then resent the power to ON.
- . Is there no foreign matter caught in the cooling fan?
- Lighting or blinking in red
- Turned off
- Lighting in red
- There is a possibility that the interior portion has become heated. Turn the power OFF and wait at least 20 minutes. After the unit has sufficiently cooled down, please make confirmation of the following item, and then resent the power to ON.
- . Is there blockage of the air passage aperture?
- . Is the air filter is dirty?
- . Does the peripheral temperature exceed 35 C?
- Lighting in green
- Alternative blinking in the red
- There is a possibility that the interior portion has become overcooled. Please use the unit within the usage temperature parameters (0 C to 35 C). After the treatment, resent the power to ON.
- Lighting in green
- Simultaneous blinking in red
- It is time to clean the air filter, or there is no air filter. Please immediately turn the power off, and clean or change the ai...
- Phenomena That May Easily Be Mistaken For Machine Defects
- NOTE:
- Phenomenon
- Cases not involving a machine defect, and Items to be confirmed
- Power does not come ON.
- The main power source is not ON.
- Turn on the main power.
- The electrical power cord is not plugged in.
- Correctly connect the power cord.
- The main power source has been interrupted during operation, such as by a power outage (blackout), etc.
- Be sure to press the “°³” (power OFF) side of the main power switch, and leave this OFF for at least 20 minutes. After the unit has sufficiently cooled down, turn ON the power source.
- Neither sounds nor pictures are outputted.
- The input changeover settings are mismatched.
- Select the input signal, and correct the settings.
- No signal is being inputted.
- Correctly connect the connection cables.
- Pictures are displayed, but no sounds are heard.
- The electrical wiring to this unit is not correctly connected.
- Correctly connect the connection cables.
- The volume setting has been set at (or adjusted to) an extremely low level.
- Adjust the VOLUME setting to a higher level.
- The MUTE mode is the current setting.
- Press the MUTE button to release (change) the MUTE mode setting.
- Sounds are heard, but no pictures are displayed.
- The electrical wiring to this unit is not correctly connected.
- Correctly connect the connection cables.
- The brightness setting has been set at (or adjusted to) an extremely low level.
- Adjust the BRIGHT setting to a brighter level.
- The lens cap has not been removed.
- Remove the lens cap.
- Phenomenon
- Cases not involving a machine defect, and Items to be confirmed
- Colors have a faded- out appearance, or Color tone is poor.
- Color settings are not correctly adjusted.
- Perform picture adjustments by changing the COLOR BAL R, COLOR BAL G, COLOR BAL B, COLOR, and/or the TINT settings, etc.
- Pictures appear dark.
- The brightness setting and/or contrast setting has not been properly adjusted.
- Perform picture adjustments by changing the BRIGHT and/or CONTRAST settings, etc.
- The WHISPER mode is the current setting.
- Change (by releasing) from the WHISPER mode.
- Lamp is approaching the end of its product lifetime.
- Exchange the old lamp with a new lamp.
- Pictures appear blurry.
- Either the FOCUS setting or the H PHASE is not properly adjusted.
- Adjust the focus and the H PHASE setting.
- NOTE:
- Warranty And After-Service
- Related Messages
- Specifications
- Customer Support
- LIMITED WARRANTY
- Appendix
- Power Cord Safety Guidelines
- USA UL
- Canada CSA
- Germany VDE
- Switzerland SEV
- Britain BASE/BS
- Japan Electric Appliance Control Act
- AC PLUG CORD PRECAUTIONS FOR THE UNITED KINGDOM
- FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY.
- IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET THEN THE PLUG SHOULD BE CUT OFF AND DISPOSED OF SAFELY.
- THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED INTO AN APPROPRIATE SOCKET.
- If a new plug is to be fitted, please observe the wiring code as shown below.
- If in any doubt, please consult a qualified electrician.
- WARNING: THIS APPLIANCE MUST BE EARTHED.
- IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:
- Green-and-Yellow: Earth
- Blue: Neutral
- Brown: Live
- If the coloured wires of the mains lead of this appliance do not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:
- The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by the letter E or by the Earth symbol or coloured GREEN or GREEN-AND-YELLOW.
- The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with the letter N or coloured BLAC...
- IMPORTANT NOTICE CONCERNING POWER CORD SELECTION
- The power cord set for this unit has been enclosed and has been selected according to the country of destination and must be use...
- The female receptacle of the cord set must meet CEE-22 requirements and may look like (Figure A1 below):
- For the United States and Canada
- In the United States and Canada the male plug is a NEMA5-15 style (Figure A2), UL Listed, and CSA Labeled. For units which are m...
- For European Countries
- In Europe you must use a cord set which is appropriate for the receptacles in your country. The cord set is HAR-Certified, and a special mark that will appear on the outer sheath, or on the insulation of one of the inner conductors.
- If you have any questions concerning which proper power cord to use, please consult with the dealer from whom you have purchased the product.
- Compliance Information for U.S.A.
- Compliance Information for Canada
- Compliance Information for European Countries
- User Information for all Countries
- Power Cord Safety Guidelines
45 ViewSonic PJ510
Compliance Information for U.S.A.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Warning
To assure continued FCC compliance, the user must use grounded power supply cord and the provided
shielded video interface cable with bonded ferrite cores. If a BNC cable is going to be used, use only a
shielded BNC(5) cable. Also, any unauthorized changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this device.
Instructions to Users
This equipment complies with the requirements of FCC (Federal Communication Commission) equipment provided that
the following condition is met. Use the cables which are included with the projector or specified.
Compliance Information for Canada
Notice: This class B digital apparatus complies with Canada ICES-003.
AVIS: Cet appeil numerique de la Classe B conforme a la norme NMB-003 du Canada.
Compliance Information for European Countries
CE Conformity
The device complies with the requirements of the EEC directive 89/336/EEC as amended by 92/
31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility,” and 73/23/EEC as
amended by 93/68/EEC Art.13 with regard to “Safety.”
User Information for all Countries
NOTICE: Use the cables which are included with the projector or specified.
