User guide

11 ViewSonic PJ853
E
N
G
L
I
S
H
Other Information
Specifications
1
May require a Macintosh adapter
LCD Ty p e
Pixels
Colors
Three 0.7” 800 x 600 polysilicon, active matrix TFT LCD
1,440,000 (800 dots x 600 lines x 3 colors)
16.7 million
Lens Ty p e
Focal length
Keystone correction
Manual zoom (1.2x), manual focus
F2.0 ~ 2.3 (f = 17.7 - 21.2 mm)
Fixed 6:1 upward shift, normal at 10° ~ 12° projection angle
Display Image size
Focus distance
Aspect ratio
Orientation
76.2 to 762 cm (30” to 300” inches)
0.7 to 9.0 m (2.3 to 29.5 feet)
4:3
Front/rear desktop, front/rear ceiling
Lamp Lamp
Lamp life
Replacement lamp
UHB, 130 watts, ultra compact, replaceable
2000 hours
Part number RLC-130-03A
Audio Power 1 watt mono
Input signal RGB analog
Video
S-video
Frequency
Input bandwidth
75 ohms, 0.7vp-p H/V separated, composite (TTL)
NTSC / NTSC 4.43, PAL, SECAM (1.0 Vp-p, 75 ohms)
Luminance signal 0.7 Vp-p, 75 ohms termination
Chrominance signal 0.29Vp-p (NTSC), 0.30Vp-p (PAL), 75
ohms termination
f
h
: 15.75/15.63, 25-78 kHz f
v
:56-120Hz
110 Hz
Compatibility PC
Macintosh
1
Video
Compatible up to 1024 x 768 (compressed)
Compatible up to 1024 x 768 (compressed)
NTSC,NTSC4.43,PAL(-BGHI),PAL-M,PAL-N,PAL60,
SECAM
Remote range Angle
Distance
30 degrees cone angle
3m(10feet)
Resolution Maximum
Recommended
1024 x 768 @ 75Hz
800 x 600 @ 60Hz
Input ports RGB
Video
S-video
Audio
Serial control
15-pin mini D-sub
RCA (x1)
Mini DIN 4-pin (x1)
Stereo mini jack
15-pin mini D-sub
Power Voltage
Consumption
100-120/220-240 VAC 50/60 Hz (auto switch)
200 watts
Operating conditions
Storage conditions
Temperature
Humidity
Altitude
Temperature
Humidity
Altitude
0° to 35°C (32° to 95°F)
10% to 85% (no condensation)
0 to 2,100 m (0 to 7,000 feet)
-20° to 60°C (-4° to 140°F)
10% to 85% (no condensation)
0 to 2,100 m (0 to 7,000 feet)
Dimensions and weight Projector 2.4 kgs (5.3 lbs)
210 x 289 x 76 mm (8.3 x 11.4 x 3.0 inches)
Regulations FCC class B, UL, C-UL, CE/TUV
