3. LED INDICATORS
Green LED:
Off: No sunlight or not enough sunlight. Charger off.
Fast flashing: Bulk charge.
On: Absorption charge.
Slow flashing: Float charge.
LED=Green: battery fully charged (> 48,8V)
LED=Orange: battery ok (48,8V - 46V)
LED=Red: battery low (44,8V)
LED=Flashing Red: battery fully discharged (< 44,8V)
(load output cut off level: 44,8V)
LED=ON: load output is on.
LED=OFF: load output is off.
LED=Slow flashing: Overload.
LED=Fast flashing: Short Circuit
Please note:
1. The load output will cut off in case of over load or short circuit.
The load output will attempt to restart after 30 seconds.
2. After over discharge, the load will reconnect automatically
when the battery is recharged to 52,4V.
3. After over discharge, the load can be reconnected manually by
pressing the on/off push button, if the battery voltage exceeds
50,4V.
