User's Manual
SER8300 Series
7
Installation Guide
Schneider Electric- Small Building Systems Tel. Americas: North Andover, MA 1-800-225-0962 Tel. Europe: Malmö, Sweden +46 40 38 68 50 Tel. Asia Pacific: Hong Kong +852 2565 0621
028-0418-01 www.schneider-electric.com/buildings October 2013 ct
© 2013 Schneider Electric. All rights reserved.
DIMENSIONAL DRAWING
86 mm (3.378”)
120 mm (4.722”)
25 mm
(0.990”)
