Specifications
Controller power requirements 7.0 VDC +/- 10% 2.4 watts minimum
Operating conditions
0 °C to 50 °C ( 32 °F to 122 °F )
0% to 95% R.H. non-condensing
Storage conditions
-30 °C to 50 °C ( -22 °F to 122 °F )
0% to 95% R.H. non-condensing
Temperature sensor Local 10 K NTC type 2 thermistor
Temperature sensor resolution ± 0.1 °C ( ± 0.2 °F )
Temperature control accuracy ± 0.5 ° C ( ± 0.9 °F ) @ 21 °C ( 70 °F ) typical calibrated
Humidity sensor and calibration Single point calibrated bulk polymer type sensor
Humidity sensor precision
Reading range from 10-90 % R.H. non-condensing 10
to 20% precision is 10%
20% to 80% precision is 5%
80% to 90% precision is 10%
Humidity sensor stability Less than 1.0 % yearly (typical drift)
Dehumidication setpoint range 30% to 95% R.H.
Occ, Stand-By and Unocc cooling setpoint range 12.0 to 37.5 °C ( 54 to 100 °F )
Occ, Stand-By and Unocc heating setpoint range 4.5 °C to 32 °C ( 40 °F to 90 °F )
Room and outdoor air temperature display range -40 °C to 50 °C ( -40 °F to 122 °F )
Proportional band for room temperature control Cooling & Heating: Default: 1.8°C ( 3.2°F )
Binary inputs
Dry contact across terminal BI1,
BI2 & UI3 to Scom
Wire gauge 14 gauge maximum, 22 gauge recommended
Approximate shipping weight 0.34 kg ( 0.75 lb )
Safety Standards (all models)
LVD Directive 2006/95/EC
UL 61010-1 (2nd edition)
CSA 61010-1(3rd edition)
IEC 61010-1 (3rd edition)
EMC Standards (all models)
EMC Directive 2004/108/EC
IEC 61326-1:2005
FCC 15 Subpart B
ICES-003
Radio Standards (wireless models)
R&TTE Directive 1999/5/EC
IEC 61326-1:2005
EN 301 489-1 V1.9.2
EN 301 328 V1.8.1
FCC 15 Subpart C
RSS 210
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE
MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY
APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID
THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
Check with your local government for instruction on disposal of this product.
