ENTER SET-UP SCREEN
Touch and hold this point
for 3 seconds to enter set-up mode
SET-UP SCREEN DISPLAY
Return to
home screen
General Note:
Setup
Network
Configuration
Setpoints - Display
Service view
Test outputs
Adjustable parameter
Non-adjustable parameter
Note: If a conguration/installer
password is activated to prevent
unauthorised access to the
conguration menu parameters, a
password entry prompt shows to
prevent access to device conguration
components.
Discover Mode The Controller
becomes discoverable on the wireless
ZigBee
®
network for 1 minute (this
button is hidden if ZigBee
®
settings are
not congured)
Enter BACnet
®
& ZigBee
®
network settings
Enter parameter conguration menu
Enter setpoint & display settings
Enter output testing mode
Enter status and service view
Note: The "Network" button does not show if no
BACnet
®
or ZigBee
®
card is installed.
