User's Manual

SER8300 Series
2
Installation Guide
Schneider Electric- Small Building Systems Tel. Americas: North Andover, MA 1-800-225-0962 Tel. Europe: Malmö, Sweden [phone] Tel. Asia Pacific: Hong Kong [phone]
028-0418-01 www.schneider-electric.com/buildings October 2013 ct
© 2013 Schneider Electric. All rights reserved.
SER8000 Controller SC3000 Relay Pack
DISCLAIMER
• The SER8000 series controller is only to be used in conjunction with the SC3000 line voltage switching relay pack. Together they are used
as operating controls for high voltage fan coil units.
• If replacing an existing Line Voltage FCU Controller, label the wires before removal of the Controller.
• Electronic controls are static sensitive devices. Discharge yourself correctly before manipulating and installing the Terminal Equipment
Controller. A short circuit or wrong wiring may permanently damage the Terminal Equipment Controller or the equipment.
• All SER8300 series controls are designed for use as operating controls only and are not safety devices. These instruments have
undergone rigorous tests and verication prior to shipping to ensure proper and reliable operation in the eld. Whenever a control failure
could lead to personal injury and/or loss of property, it becomes the responsibility of the user/installer/electrical system designer to
incorporate safety devices such as relays, ow switches, thermal protections, and/or an alarm system to protect the entire system against
any catastrophic failures. Tampering with the devices or unintended application of the devices results in a void of warranty.
• If the equipment is used in a manner not specied by the manufacturer, the protection provided by the equipment may be impaired.
• These devices are not serviceable and must be returned to the supplier for any repair.
•A switch or circuit breaker must be installed. It must be suitably located, easily reached, and marked as the disconnecting device.
•Never apply more than 24VDC to get applied to the Controller
•This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
IMPORTANT SYMBOLS
Products marked with this symbol state that the manuals must be consulted in all cases to any hazards.
This product has been tested to the requirements of CAN/CAS-C22.2 No. 61010-1, second edition, including Amendment 1, or a
later version of the same standard incorporating the same level of testing requirements.
Alternating Current
Direct Current
Equipment protected throughout by DOUBLE INSULATION or REINFORCED INSULATION
