ENCLOSURE: ASSY.
SECONDARY HP2/NP2
I-23579
NEXT ASSY.
ECN# 4015 NEW DWG. 17DEC97 S.WERNERA
3
4
2
6
DESCRIPTION
TRAP TUBE ASSY: COMPLETE, HP2
5 6 2 3 4
ITEM
1
I-23572HP2 1
VALCO # QTY.
HOLE PLUG: 1/2"
HW-7603 2
SCREW,PHMS: 6-32 X 3/8 LG
HWSC-PL6-6 4
FEET: RUBBER, STICK-ON
HW-1658
4
BASE: GAS PURIFIER HP2/NP2
I-23542 1
ENCLOSURE: ASSY. HP2/NP2
I-23575
1
I-23580
1
5
NITROGEN MODELS USE I-23572-02
*
*
TAG: 1*2" METALIZED
7
I-TAG73T1-795 1
