User guide

7
Technical Drawings
C
USA PROJECTION
SHEET
SIZE DRAWING NO.
APPROVED
SCALE
DRAWN DESIGNED
REVISIONS
LTR DESCRIPTION DATE INITIATED
Valco Instruments Co., Inc.
FRACTIONS DEC. ANGLES OTHERWISE SPECIFIED TOLERANCES UNLESS
1/64"
.X.1
.XX.01
1
.XXX.005
CHECKED FILE NAME SUB-DIR
THIS DOCUMENT AND THE INFORMATION WHICH IT CONTAINS SHALL NOT BE USED, EXPLOITED OR SOLD, AND SHALL NOT BE REVEALED OR DISCLOSED TO OTHERS WITHOUT THE EXPRESSED WRITTEN PERMISSION OF VALCO. THIS DOCUMENT SHALL REMAIN THE PROPERTY OF VALCO AND SHALL BE RETURNED UPON DEMAND.
63
DATE
OF
2
S.WERNER 17DEC97 S.WERNER
23575 HP2
23575
ENCLOSURE: SUB-ASSY:
HP2/NP2
I-23575
NEXT ASSY.
1
4B
4A
3
NEW DWG. GETTER REDESIGN (HP2) ECN #4015 17DEC97 S.WERNERA
7
THREAD GAP
11
12
10
9
SO THERE ARE ABOUT 2 THREADS SHOWING ~ .050 LOCK THREADED SPACERS TOGETHER WITH PLIERS WHEN ADJUSTING FOR THREAD GAP
13
ENSURE CLOSE PARALLEL FIT OF AND
ASSEMBLE AS SHOWN:
10
11
8
ASSEMBLED PROFILE
14
15
23579
ENCLOSURE: COVER, HP2/NP2 ENCLOSURE: OVEN, HP2/NP2
HEATER: CARTRIDGE 42W, 24V 6" X 3/8 NUT, HEX: 10-32 X 5/16 SS HEATER BLOCK-A: HP2*NP2 COMPLETE
JACK: POWER, PANEL SLOT MT, .1 ID PIN
STANDOFF: 10-32*1/2, 5/16 OD, SS
SPACER: #10*1 1/8, 5/16 OD, SS
14 15
12 13 11 10 9
SCREW, PHMS: 4-40 X 1/4 LG
3 2 1
ITEM
DESCRIPTION
PARTS LIST
HWJAX-10
I-21208-48
HWSP-1169
I-23574-01
HWNUT-HEX#10-5
HWSO-1751
I-23574-02
1
1
2
4
2
1 1
QTY
I-23541-02
HWSC-PL4-4
I-23541-01
VALCO #
4
1 1
4A
INSULATION, FRONT: HP2*NP2
I-23577
INSULATION, REAR: HP2*NP2
4B
I-23578
6
U-FELT SERIES MICROFIBER 3/4" TH
I-E-FELT
.041
7
TAPE: HIGH TEMP 1" WIDE, 100' ROLL
CI608104
1.00'
HWSC-SC10-48
2
SCREW, SHCS: 10-32 X 3" LG, SS
8
HEATER BLOCK-B: HP2*NP2 COMPLETE
6
1 1
B ECN# 4908 CHANGE ITEM 7 TO 1" WIDE (1.5") 24SEP99 JDURR
* *
1.5" X 4.0"
