Chapter 1 WiFi Advisor Overview
About the WiFi Advisor
WiFi Advisor Wireless LAN Analyzer User’s Guide
Page 6 22073751, Rev. 002 December 2014
Front view
The front view is shown in Figure 3.
USB
There are two USB connectors. They are used to connect host devices to the WiFi
Advisor and as an alternative path for firmware download.
• The standard USB connector is a master/host interface.
• The mini-USB is a device/slave interface.
Ethernet
The RJ-45 connector interface is reserved for future Ethernet measurement func-
tions.
Figure 3 WiFi Advisor front view
USB 2.0 device
10/100/1000 Ethernet
USB 2.0 host
