Service manual

H-21
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
RF Unit
L 1046 COIL 0.014uH AS050425-14NJ L0022827 1- B a4
L 1047 COIL 0.014uH AS050425-14NJ L0022827 1- B a4
L 1048 COIL 0.012uH AS030321-12NJ L0022819 1- B b4
L 1049 COIL 0.012uH AS030321-12NJ L0022819 1- B b4
L 1050 M.RFC 0.0047uH HK1608 4N7S-T L1690512 1- B b4
L 1051 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B e5
L 1052 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B e5
L 1053 M.RFC 0.082uH HK1608 82NJ-T L1690527 1- B e3
L 1055 COIL 0.014uH AS050425-14NJ L0022827 1-5 B e5
L 1055 COIL 0.017uH AS030616-17NK L0022678 VERSION A 6- B e5
L 1055 COIL 0.014uH AS050425-14NJ L0022827 VERSION D 6- B e5
L 1056 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B e5
L 1057 M.RFC 0.22uH HK1608 R22J-T L1690940 1- B d5
Q 1001 TRANSISTOR DTC114TE TL G3070225 1- B h5
Q 1004 IC NJM7808DL1A(TE1) G1093802 1- A C4
Q 1005 IC TDA1519CTH G1093778 1- B i3
Q 1006 FET RTQ030P02 G4070015 1- A C3
Q 1007 TRANSISTOR DTA144EE TL G3070074 1- A C3
Q 1009 TRANSISTOR DTC144EE TL G3070075 1- A A3
Q 1010 FET RTQ030P02 G4070015 1- A F3
Q 1011 TRANSISTOR DTC114TE TL G3070225 1- A D3
Q 1012 TRANSISTOR DTC144EE TL G3070075 1- A C3
Q 1013 TRANSISTOR UMG2N TR G3070088 1- A F4
Q 1014 IC NJU4053BV-TE1 G1092927 1- A C6
Q 1014 IC CD4053BPWR G1093864 6- A C6
Q 1015 FET RTQ030P02 G4070015 1- A F4
Q 1016 IC NJU4053BV-TE1 G1092927 1- A C6
Q 1016 IC CD4053BPWR G1093864 6- A C6
Q 1017 TRANSISTOR UN911F-(TX) G3070150 1- A F4
Q 1018 TRANSISTOR DTC144EE TL G3070075 1- A F3
Q 1019 TRANSISTOR DTC114TE TL G3070225 1- A F4
Q 1020 TRANSISTOR 2SA1774 TL R G3117748R 1- A H4
Q 1021 IC LA8630M-B-TE-R G1093452 1- B g6
Q 1022 TRANSISTOR 2SC3357-T2 RF G3333577F 1- B b4
Q 1023 TRANSISTOR DTC144EE TL G3070075 1- B h6
Q 1024 TRANSISTOR DTC144EE TL G3070075 1- B g5
Q 1025 TRANSISTOR 2SC4617 TL R G3346178R 1- B i6
Q 1026 TRANSISTOR 2SC4617 TL R G3346178R 1- B j5
Q 1027 TRANSISTOR 2SC4617 TL R G3346178R 1- B i5
Q 1028 IC RA45H4452M-01 G1093821 1-5 A D1
Q 1028 IC S-AU83L G1093920 25W VER.A 6- A D1
Q 1028 IC RA30H4452M-22 G1093885 25W VER.D 6- A D1
Q 1028 IC RA45H4047M-01 G1093848 45W VER A 6- A D1
Q 1028 IC RA45H4452M-01 G1093821 45W VER D 6- A D1
Q 1029 IC M62364FP 600D G1093033 1- A E7
Q 1030 TRANSISTOR DTC144EE TL G3070075 1- B i5
Q 1031 TRANSISTOR DTA124EE TL G3070116 1- B i5
Q 1032 TRANSISTOR DTC144EE TL G3070075 1- B g6
Q 1033 TRANSISTOR DTC144EE TL G3070075 1- A H3
Q 1034 IC BD6111FV-E2 G1093746 1- B f3
Q 1035 IC SPM5001 G1093686 1- B c6
Q 1036 IC NJM2125F(TAPE) G1093894 1- B f3
Q 1037 IC AK2345(TAPE) G1093184 1- B e7
Q 1038 TRANSISTOR 2SC5226-4-TL G3352268D 1- B d3
Q 1039 TRANSISTOR UMC5N TR G3070137 1- A F4
Q 1044 TRANSISTOR 2SA1774 TL R G3117748R 1- B e3
Q 1045 TRANSISTOR DTC114TE TL G3070225 1- B h5
Q 1046 TRANSISTOR 2SC3357-T2 RF G3333577F 1- B b5
Q 1047 TRANSISTOR DTC144EE TL G3070075 1- B e4
Q 1049 TRANSISTOR 2SC5226-4-TL G3352268D 1- B e4
Q 1051 TRANSISTOR DTC144EE TL G3070075 1- A C5
Q 1053 TRANSISTOR DTC144EE TL G3070075 1- B e5
Q 1054 FET 2SK508-T2B K52 G3805087B 1- B e5
Q 1055 TRANSISTOR DTC144EE TL G3070075 1- B b6
Q 1056 TRANSISTOR DTC114TE TL G3070225 1- B d4
Q 1057 TRANSISTOR 2SC5226-4-TL G3352268D 1- B c6
Q 1058 TRANSISTOR 2SC3356-T2B R24 G3333567D 1- B e5
Q 1059 TRANSISTOR 2SC5226-4-TL G3352268D 1- B a5
Q 1060 IC TAR5S35(TE85L) G1093939 1- A D5
Q 1061 TRANSISTOR XN1501-(TX) G3070149 1- B g4
Q 1062 TRANSISTOR 2SB1201S-TL G3070195 1- B g4
Q 1063 IC BU4066BCFV-E2 G1093537 1- A D6
Q 1063 IC CD4066BPWR G1093865 6- A D6
