Table Of Contents

H-18

Parts List

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

RF Unit

C 1357 CHIP CAP. 1uF 10V B GRM40B105K10PT K22100802 1- A E6

C 1359 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 1-5 B c4

C 1359 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 VERSION D 6- B c4

C 1360 CHIP CAP. 8pF 50V CH GRM36CH080D50PT K22178210 1-5 B c4

C 1360 CHIP CAP. 12pF 50V CH GRM36CH120J50PT K22178214 VERSION A 6- B c4

C 1360 CHIP CAP. 8pF 50V CH GRM36CH080D50PT K22178210 VERSION D 6- B c4

C 1361 CHIP CAP. 10pF 50V CH GRM36CH100D50PT K22178212 1- B c4

C 1362 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A E6

C 1369 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 1-5 B c4

C 1369 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 VERSION A 6- B c4

C 1369 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 VERSION D 6- B c4

C 1370 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 1-5 B c4

C 1370 CHIP CAP. 5pF 50V CH GRM36CH050C50PT K22178207 VERSION A 6- B c4

C 1370 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 VERSION D 6- B c4

C 1371 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 1-5 B c4

C 1371 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 VERSION A 6- B c4

C 1371 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 VERSION D 6- B c4

C 1372 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 1- B c4

C 1374 CHIP CAP. 0.022uF 16V B GRM36B223K16PT K22128806 1- A D6

C 1375 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1-5 A E3

C 1375 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 VERSION A 6- A E3

C 1375 CHIP CAP. 10pF 50V CH GRM36CH100D50PT K22178212 VERSION D 6- A E3

C 1376 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 1-5 B d4

C 1376 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 VERSION A 6- B d4

C 1376 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 VERSION D 6- B d4

C 1377 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 1- B d4

C 1378 CHIP CAP. 12pF 50V CH GRM36CH120J50PT K22178214 1- B e5

C 1379 CHIP CAP. 15pF 500V CH GRM42-6CH150J500PT K22271217 1- A I2

C 1380 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1-5 B e3

C 1380 CHIP CAP. 10pF 50V CH GRM36CH100D50PT K22178212 VERSION A 6- B e3

C 1380 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 VERSION D 6- B e3

C 1381 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B d3

C 1382 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B d3

C 1383 CHIP CAP. 2pF 50V CK GRM36CK020C50PT K22178204 1-5 B a3

C 1383 CHIP CAP. 2pF 50V CK GRM36CK020C50PT K22178204 VERSION D 6- B a3

C 1384 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 VERSION A 6- B c4

C 1385 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 VERSION A 6- B c4

C 1386 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1-5 B c4

C 1386 CHIP CAP. 56pF 50V CH GRM36CH560J50PT K22178230 VERSION A 6- B c4

C 1386 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 VERSION D 6- B c4

C 1387 CHIP CAP. 10pF 50V CH GRM36CH100D50PT K22178212 1- B c4

C 1388 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 VERSION A 6- B c4

C 1389 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 1- B c4

C 1391 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b4

C 1392 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B b4

C 1393 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B f6

C 1394 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c4

C 1395 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b4

C 1396 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A I4

C 1397 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 1-5 B c4

C 1397 CHIP CAP. 8pF 50V CH GRM36CH080D50PT K22178210 VERSION A 6- B c4

C 1397 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 VERSION D 6- B c4

C 1398 CHIP CAP. 1pF 50V CK GRM36CK010B50PT K22178287 1-5 B c4

C 1398 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 VERSION A 6- B c4

C 1398 CHIP CAP. 1pF 50V CK GRM36CK010B50PT K22178287 VERSION D 6- B c4

C 1399 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B b4

C 1400 CHIP CAP. 5pF 50V CH GRM36CH050C50PT K22178207 VERSION A 6- B c4

C 1402 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B c4

C 1404 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A G7

C 1405 CHIP CAP. 3pF 50V CJ GRM36CJ030B50PT K22178290 1-5 B e5

C 1405 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 VERSION A 6- B e5

C 1405 CHIP CAP. 3pF 50V CJ GRM36CJ030B50PT K22178290 VERSION D 6- B e5

C 1406 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A C7

C 1407 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D7

C 1408 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D7

C 1409 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D6

C 1410 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D7

C 1411 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D6

C 1412 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D7

C 1413 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D6

C 1414 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D7

C 1415 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D6

C 1417 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D6
