H-17

Parts List

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

RF Unit

C 1283 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B e5

C 1284 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d5

C 1285 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- A B7

C 1286 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- A C7

C 1287 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A J6

C 1288 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A J5

C 1289 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A J5

C 1290 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D4

C 1291 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A B6

C 1293 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A D4

C 1294 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A B6

C 1295 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- A D4

C 1296 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c7

C 1297 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c7

C 1298 CHIP CAP. 0.022uF 16V B GRM36B223K16PT K22128806 1- B c6

C 1299 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A A2

C 1300 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D4

C 1301 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- A I6

C 1302 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A J6

C 1303 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A H6

C 1304 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- A J6

C 1305 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c6

C 1306 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- B d6

C 1307 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A A5

C 1308 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A J6

C 1309 CHIP CAP. 82pF 50V CH GRM36CH820J50PT K22178234 1- A J6

C 1310 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c7

C 1311 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A J6

C 1312 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c7

C 1313 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d7

C 1314 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c6

C 1315 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c6

C 1316 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B j1

C 1317 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A I7

C 1318 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c6

C 1319 CHIP CAP. 82pF 50V CH GRM36CH820J50PT K22178234 1- A J6

C 1320 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A I6

C 1321 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A A6

C 1322 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A A6

C 1323 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A I6

C 1324 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- A I6

C 1325 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A B2

C 1326 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A J6

C 1327 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1- A J6

C 1328 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A I6

C 1329 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- B d7

C 1330 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I6

C 1331 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B c6

C 1332 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c7

C 1333 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B c7

C 1334 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A J7

C 1335 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A J7

C 1336 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I7

C 1337 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c7

C 1338 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d7

C 1339 CHIP CAP. 330pF 50V B GRM36B331K50PT K22178803 1- A I6

C 1340 CHIP CAP. 33pF 50V CH GRM36CH330J50PT K22178224 1- B c7

C 1341 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B c6

C 1342 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B i2

C 1343 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B c7

C 1344 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A J7

C 1345 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A H7

C 1346 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A J7

C 1347 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A A1

C 1348 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A A2

C 1349 CHIP CAP. 560pF 50V B GRM36B561K50PT K22178806 1- A I7

C 1350 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A I7

C 1351 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I6

C 1352 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I7

C 1353 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A B2

C 1354 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A B2

C 1355 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I7

C 1356 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A B5
