H-14

Parts List

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS.

LOT

SIDE

LAY ADR

RF Unit

C 1057 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 VERSION A 6- B b4

C 1057 CHIP CAP. 9pF 50V CH GRM36CH090D50PT K22178211 VERSION D 6- B b4

C 1058 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 1-5 B b4

C 1058 CHIP CAP. 9pF 50V CH GRM36CH090D50PT K22178211 VERSION A 6- B b4

C 1058 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 VERSION D 6- B b4

C 1059 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- A H3

C 1060 CHIP CAP. 100pF 500V CH GRM42-6CH101J500PT K22271237 1- A G3

C 1062 CHIP CAP. 470pF 50V B GRM36B471K50PT K22178805 1- A H3

C 1064 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B c3

C 1065 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1-5 B b4

C 1065 CHIP CAP. 39pF 50V CH GRM36CH390J50PT K22178226 VERSION A 6- B b4

C 1065 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 VERSION D 6- B b4

C 1066 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B g6

C 1068 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g5

C 1069 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g6

C 1070 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B f6

C 1071 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g5

C 1072 CHIP CAP. 1uF 10V B GRM40B105K10PT K22100802 1- B h4

C 1073 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A C5

C 1074 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g6

C 1075 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B f7

C 1076 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B h4

C 1077 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B g6

C 1079 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B c3

C 1080 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A I3

C 1081 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A H3

C 1082 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B g6

C 1083 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 1-5 B b4

C 1083 CHIP CAP. 10pF 50V CH GRM36CH100D50PT K22178212 VERSION A 6- B b4

C 1083 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 VERSION D 6- B b4

C 1084 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B g6

C 1085 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- B f6

C 1087 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A G3

C 1089 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A F3

C 1090 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g6

C 1091 CHIP CAP. 10pF 50V CH GRM36CH100D50PT K22178212 1- B b4

C 1092 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A G3

C 1093 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A E3

C 1095 CHIP TA.CAP. 4.7uF 25V TESVC1E475M12R K78140011 1- A F3

C 1095 CHIP TA.CAP. 4.7uF 35V TEMSVC1V475M12R K78160036 6- A F3

C 1096 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B g4

C 1097 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- A E3

C 1098 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B f7

C 1099 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- A G3

C 1100 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B g4

C 1101 CHIP CAP. 0.022uF 16V B GRM36B223K16PT K22128806 1- B f7

C 1102 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- A F3

C 1103 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A D5

C 1104 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A H3

C 1105 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b4

C 1106 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A H4

C 1107 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A H3

C 1108 CHIP CAP. 0.047uF 10V B GRM36B473K10PT K22108801 1- A H3

C 1109 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A F6

C 1110 CHIP CAP. 0.0022uF 50V B GRM36B222K50PT K22178813 1- A H3

C 1111 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A E6

C 1113 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b4

C 1114 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- A E2

C 1115 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E6

C 1116 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B e3

C 1117 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- A E3

C 1118 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A E7

C 1119 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 1-5 B b4

C 1119 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 VERSION A 6- B b4

C 1119 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 VERSION D 6- B b4

C 1120 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B b4

C 1121 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A F6

C 1122 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A B3

C 1124 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D4

C 1125 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E5

C 1126 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B f6

C 1127 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c5

C 1128 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c5
