Operating instructions

Clearance Requirements
Minimum Clearances to Combustible
Materials
Measure side clearances as shown in Figures 3 and 4
from the outer edge of the cast iron stove top. Measure
rear clearances from the outermost surface of the steel
rear skirt.
The Stardance heater is approved for installation into an
alcove constructed of combustible materials to the dimen-
sions and clearances shown on the next page.
The same clearances apply in a standard parallel instal-
lation.
Installation Requirements
The installation must conform with local codes or, in the
absence of local codes, with the National Fuel Gas Code,
ANSI Z223.1/NFPA 54 - latest edition. (EXCEPTION: Do
not derate this appliance for altitude. Maintain the mani-
fold pressure at 3.5 inches w.c. for Natural Gas, and 10
inches w.c. for Propane).
In Canada, installation must be in accordance with the cur-
rent CSA B-149.1 Installation Codes and/or local codes.
The installation should be done by a qualied service
person who is familiar with the building codes and
installation techniques appropriate for your area to
accomplish a safe and effective installation.
Your dealer or your local gas supplier will be able to
refer a qualied service person.
WARNING: Due to high temperatures, the
HEATER should be located out of trafc and
away from furniture and draperies.
The surface of the Heater Is hot when it is in use.
Young children should be watched carefully when
they are in the same room when the Heater is in use,
and they should be taught to avoid the hot surface.
Keep any objects that can burn well away from the
Heater, and observe the recommended clearances
that follow.
A
B
E
C
D
ST207a
Stardance
Stove locations
9/28/00 djt
Figure 2 Possible stove locations.
ST207
Warning:
• Always maintain required clearances (air
spaces) to nearby combustibles to prevent
re hazard. Do not ll air spaces with insula-
tion. All venting components must maintain a
1” (25 mm) clearance to combustible materials.
Maintain a 6” (150 mm) clearance when using a
single wall pipe.
• The gas appliance and vent system must be
vented directly to the outside of the building and
never be attached to a chimney serving a sepa-
rate solid fuel or gas-burning appliance. Each
direct vent appliance must use its own separate
vent system. Common vents are prohibited.
• Refer to the manufacturer’s instructions includ-
ed with the venting system for complete instal-
lation procedures.
Locating the Stove
In choosing a location for the stove, consider:
• The location of outside walls;
• Where additional heat is needed:
• Where family members gather most often;
• The vent system requirements.
NOTE: We do not recommend the use of wallpaper next
to this stove. Over time, radiant heat may cause the wall-
paper to shrink, or may adversely affect the binders in the
wallpaper adhesive.
DANGER
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Un panneau vitré chaud peut
causer des brûlures.
Laissez refroidir le panneau
vitré avant d’y toucher.
Ne laisser jamais les enfants
toucher le panneau vitré.
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this
appliance and shall be installed.
Une barrière visant à réduire le risque de brûlure
par le hublot chaude est fournie avec cet
appareil et doit être installé.
DANGER
6
Stardance® Direct Vent/Natural Vent Gas Heater
20306760
