Operating instructions

*Use common super glue or silicone to attach magnets.
Color Top Left End Right End Front OP Left Door*
Right
Door*
Left
Door**
Right
Door**
Classic Black 30001276 30001280 30001279 30001496 30001139 30001138 30004082 30004081
Biscuit 30003305 30003300 30003301 30003302 30003304 30003303 30004090 30004089
Bordeaux 30006752 30006750 30006751 30006753 n/a n/a 30006755 30006754
Brown Majolica 30004897 30004895 30004896 30004899 n/a n/a 30004900 30004901
Ebony Black 30001304 30001308 30001307 30001270 30001272 30001271 30004086 30004085
* These doors have a front handle.
** These doors do not have a handle, they are closed with a magnet.
Replacement Parts
Fuel Conversion Kits
Shell Enamel Parts
Ref. Description SDDVT/SDDVTCS
34. Remote Kit (Hi/Lo, Blower) (SDDVTCS Series only) RCSITEA
35. Sensor 1450 CMG-8184-0032 (for use with FSDHAG only) 10002013
36. Wiring Harness 10002582
37. Gasket, Base Pan 20002282
38. Gasket HE Door 1203687
39. Gasket Cement 1206122
40. Handle Package, Ceramic w/Screw (not shown) 0004345
42. Switch Bracket (not shown) 53821
43. Starter Pipe (not shown) 30000245
44. Rear Shroud (not shown) 20003802
45. 1/4” Fiberglass Gasket (not shown) 1203560
46. *Magnet, Door (not shown) 30004112
47. Right Burner Support Assembly 20012512
48. Tie Bracket Assembly 20012514
49. Rear Shroud Assy. (SDDVTCS Series Only) (not shown) 20300122
50. Safety Screen Barrier 30007254
Description
SDDVT
SERIES
SDDVTCS
SERIES
Conversion Kit, NG to LP 20012735 20300126
Conversion Kit, LP to NG 20012903 20300127
46
Stardance® Direct Vent/Natural Vent Gas Heater
20306760
