Replacement Parts
Ref. Description SDDVT/SDDVTCS
1. Log Set - Complete 20012551
1a. Log Rear 20012546
1b. Log Right 20012548
1c. Log Left 20012547
1d. Log Top 20012915
2. Ember Bed Assembly 20012492
3. Top Refer to Enamel Parts Chart
4. Front, Operable Door Refer to Enamel Parts Chart
5. Door Right Refer to Enamel Parts Chart
6. Door Left Refer to Enamel Parts Chart
7. Left End Refer to Enamel Parts Chart
8. Right End Refer to Enamel Parts Chart
9. Door, Control 1301087
10. Glass Frame Assembly 30000127
11. Glass 1601691
12. Gasket, Glass - Med. Knit 1203702
13. Nut, Hex Jam 3/8-16 TOPLK-Z 1203290
14. Pawl Assy, Ash Door 5004025
15. Front Steel Handle/Shaft - NI/VER 30002717
16. Restrictor Plate 20013026
17. Fan Blower (SDDVTCS Series Only) 30005069
18. Valve Nova SIT820.852 RN 20012218
18a. Valve SIT MV HI/LO 0.820.652 - Nat. (SDDVTCS Series only) 37D0117
19a. Stepper Motor - SIT820 - Nat. (SDDVTCS Series only) 50D0099
19b. Stepper Motor - SIT820 - LP (SDDVTCS Series only) 50D0100
20a. Pilot Assembly 3Way N/DV RN 0.199.706 10002264
20b. Pilot Assembly 3Way N/DV RP 0.199.703 10002265
21. Pilot Top Convertible 10002266
22. Thermocouple 24” 7531137
23. Electrode Ignitor w/Cable SIT24 10001297
24. Thermopile 18” RS 7533113
25. Nut Electrode SIT #0.974.144 57886
26. Tubing Pilot w/Fittings 1/8 x 24” 10001296
27a. Pilot Orice #62 - NG Top Convertible 37D0022
27b. Pilot Orice #35 - LP Top Convertible 37D0023
28a. Orice Hood #53 (.0595”) LP 20007347
28b. Orice Hood #38 (0.101”) Nat. 20009310
29. Ignitor Piezo w/Nut SIT 057958
30. Bracket Piezo Ignitor/Control (not shown) (SDDVTCS Series only) 20300111
31. Manifold Assembly 20012553
32. Air Shutter Assembly 20012517
33. Trim ON/OFF Switch 30000874
