Vent Termination (VC)
Storm Collar (SC)
Roof Flashing (AF)
Ceiling Support
(CS)
Trim Plate (TP)
Pipe Length
Pipe Length
Appliance Adapter
(AAV)
ST924
Vertical Venting
ST922
Selkirk seal
6/07
Gasket
Lock Tab
Inlet End
Outlet End
ST922
To Termination To Appliance
Figure 33 Joint connection.
Figure
34 Selkirk Venting Components
Pipe Length
Appliance Adapter
(AAV)
90° Elbow
(EL90)
Pipe Length
Trim Plate (TP)
(Required if Wall
Thimble is not used)
Wall Thimble (WT)
(Optional)
Horizontal Termination (HC)
ST925
Horizontal Venting
