Operating instructions

30
RFSDV34 Freestanding Direct Vent Gas Stove
10003550
Ref. Description RFSDV34
RFSDV34 (continued)
5a. Orice, Main Burner - Nat. (not shown) Refer to Rating Plate
5b. Orice, Main Burner - Prop. (not shown) Refer to Rating Plate
5c. Orice, Front Burner - Nat. (not shown) Refer to Rating Plate
5d. Orice, Front Burner - Prop (not shown) Refer to Rating Plate
6a. Orice, Top Convertible Pilot - Nat. (not shown) 100068
6b. Orice, Top Convertible Pilot - Prop. (not shown) 100069
7. Ignitor Piezo (not shown) 14D0505
8a. Pilot Assembly, 3 way DV Top Conv. - Nat. 100064
8b. Pilot Assembly, 3 way DV Top Conv. - Prop. 100065
9a. Stepper Motor - Nat. 50D0099
9b. Stepper Motor - LP 50D0100
10. Pilot Tube w/ttings SIT 1000196
11. Manifold Tube w/ttings (not shown) 57318
1. Thermopile, RN & RP 6D0566
13. Remote Kit (Hi/Lo, Blower) - TSR Series RCSITEA
14. Manifold Assembly (not shown) 1000084
15. Electrode ignitor w/cable 4” 1000197
16a. Valve SIT80 - Nat. 37D0117
16b. Valve SIT80 - LP 37D0118
17. Fan Assembly w/bracket - TSR Series 51869
18. Window Frame Assembly (complete with glass) 10001917
19. Window Glass w/Gasket Assembly Kit (not shown) 10001916
0. Window Glass Gasket Kit (not shown) 10001983
1. Front Louvre Assembly 10001370
. Cabinet Side Door 1000179
3. Control Door Assembly 10001790
4. Clamp 10000949
5. Top Grille Panel 10001791
6. Magnet, Ceramic Side Doors (not shown) 10001705
7. Screen Cabinet Top 10001749
8. Plate Relief w/Gasket Assembly (not shown) 100086
9. Thermocouple SIT 4D0808
30. Relief Plate w/Gasket Assembly Burner Tray (not shown) 1000419
31. Control Panel (not shown) 0300163
Fuel Conversion Kits
Conversion Kit, NG to LP - RFSDV34TSR Kit #RFSDV34CKPS
Conversion Kit, LP to NG - RFSDV34TSR Kit #RFSDV34CKNS
