Operating instructions

73D0024
45
KHLDV Series Gas Fireplace


1. Remove the plate located in front of the glass at the
bottom.
2. Remove rod provided for screen assembly located
beneath the cover plate.
3. Rotate the access doors on the right and left side of the
glass toward the glass.
4. Remove glass frame by releasing the three latches
located at the top of the rebox. Tilt glass away from the
unit, lift glass frame up and away from the unit. Figure
57
FP2153
remove glass frame
Figure 57 -
Remove Glass Frame
Glass Frame
FP2153



WARNING
!
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
AVERTISSEMENT
!
Un panneau vitré chaud peut
causer des brûlures.
Laissez refroidir le panneau
vitré avant d’y toucher.
Ne laisser jamais les enfants
toucher le panneau vitré.
