Operating instructions

73D0024
21
KHLDV Series Gas Fireplace


Use proper gas type for the replace you are installing.
If you have conicting gas type, do not install replace.
See dealer where you purchased the replace for proper
replace for your gas type or conversion kit.



Before installing replace and burner system, make sure
you have the items listed below.
• Test gauge connection* • Tee joint
• Equipment shutoff valve* • Pipe wrench
• Sediment trap (recommended)
• External regulator (supplied by installer)
• Piping (check local codes)
• Sealant (resistant to propane/LP gas)
• Approved exible gas line with gas connector (if
allowed by local codes — not provided)
* A CSA design-certied equipment shutoff valve with 1/8"
NPT tap is an acceptable alternative to test gauge connec-
tion. Purchase the CSA design-certied equipment shutoff
valve from your dealer.
For propane/LP connections only, the installer must supply
an external regulator. The external regulator will reduce
incoming gas pressure. You must reduce incoming gas
pressure to between 11 and 13 inches of water. If you do
not reduce incoming gas pressure, burner system regula-
tor damage could occur. Install external regulator with the
vent pointing down as shown in Figure 27. Pointing the
vent down protects it from freezing rain or sleet.

     
     


    

     

     

FP1977
external regulator
Figure 27 -
External Regulator with Vent Pointing Down
(Propane/LP Only)
FP1977
External
Regulator
100 gallon (min)
Propane/LP
Supply Tank
Vent Pointing
Down
When using copper of ex connectors use only ttings
approved for gas connections. The gas control inlet is
3/8" NPT.

       
     






      

