User Manual

* These controls perform the same function as their on-camera equivalents and are affected by changes to the Custom Settings menu.
See your camera manual for details.
1
Power contacts
2
C1 and C2 custom function buttons*
3
Strap mount
4
Control lock switch
5
Shutter release button*
6
Front dial*
7
Nonslip grip
8
1/4-20 tripod socket
9
Battery tray compartment
10
Battery tray lock
11
Battery tray
12
Locking wheel
13
Multi-selector joystick*
14
AF-ON / Image zoom*
15
AEL / Image index*
16
Rear dial*
17
Camera battery door holder
18
1/4-20 camera mounting screw
19
Battery slot 1
20
Slot 1 contacts
21
Battery slot 2
22
Slot 2 contacts
5
