BG-C14 BATTERY GRIP Designed for the Canon 5D Mark IV SLR Camera
Introduction Thank you for choosing Vello, and congratulations on your new BG-C14 battery grip purchase. Enjoy the many benefits that a battery grip offers, such as extended shooting time and more control and comfort when shooting in portrait orientation. The Vello BG-C14 is compatible with the Canon 5D Mark IV SLR camera. The BG-C14 accepts up to two Canon LP-E6 or LP-E6N rechargeable batteries.
2. Use only with the batteries and battery holders recommended in this manual. 3. Cover the power terminals with the contact cap when the BG-C14 is not in use. This prevents electrical shorts caused by metal objects touching the power terminals. 4. 5. When the battery holder is removed from the grip, remove the batteries or place the holder in a container to prevent electrical shorts caused by contact with other metal objects.
Overview 1 16 15 14 17 2 3 18 19 20 4 21 5 6 8 9 10 11 12 13 7 4
Communicate with the camera electronics. Mounting Screw Aligns with the camera’s tripod socket. 10 Multi-controller Button* 11 AF Point Selection* 12 A E Lock* 13 AF Start Button* 14 Shutter-Release Button* 15 Multi Function Button* 16 Main Dial* 3 4 Guide Pin Helps align the camera to the grip. 5 Battery Tray Lever Locks and unlocks compartment door. the battery 6 Battery Tray Compartment Houses the battery tray.
Attaching the Grip 1. Ensure that the power is turned off on the camera and that the power switch is set to OFF on the battery grip. 2. Open the camera battery chamber cover, and remove the battery from the camera battery compartment. 6 3. Slide the camera battery chamber cover’s locking pin, as indicated above, and remove the cover.
INTRODUCTION 5. Connect the BG-C14 grip to the camera. 6. Rotate the at tachment wheel in the direc tion shown by the arrow until it is firmly tightened. When removing the grip, turn the camera power off, remove the batteries, and replace the protective contact cap. 7 OVERVIEW To prevent loss, remove the protective cap and place the camera battery chamber cover into the BG-C14 battery chamber holder as indicated above. Swing the battery chamber cover shut so that it locks into place. ASSEMBLY 4.
Inserting Batteries 1. Ensure that the power is turned off on the camera and the grip. Use your fingernail to protrude the battery tray lever so you can rotate and pull as indicated above, and slide the battery tray out of the grip. 2. Canon LP-E6 or LP-E6N Batteries: Inser t up to two batteries by placing them into either slot in the battery tray, while ensuring the correct orientation as shown on the tray.
INTRODUCTION 9 Switch the grip power to ON, and then turn on the camera’s power. Check the battery level in the control panel or viewfinder. OVERVIEW 4. Rotate the battery tray lever counterclockwise, and slide the battery tray all the way into the grip. Rotate the lever as indicated above, and push the it back into place to lock the tray. ASSEMBLY 3.
Specifications Power Source 1. 2. One or two Canon LP-E6 or LP-E6N rechargeable batteries Works with the Canon AC Adapter Kit ACK-E6 (sold separately) Operating Temperature 32°F–104°F (0°C–40°C) Dimensions 5.9 × 4.6 × 3.3 in. (15.0 × 11.7 × 8.5 cm) Weight 10.9 oz. (308 g) excluding batteries Specifications and design are subject to change without notice.
ONE-YEAR LIMITED WARRANTY This VELLO product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
