Owner's manual
Table Of Contents
- Contents
- Safety information
- Note Ex-area
- 1 Product description
- 1.1 Function and configuration
- 1.3 Technical data
- 1.4 Approvals
- 1.5 Dimensions
- 1.6 Type plate
- 2 Mounting
- 2.1 Mounting instructions
- 3 Electrical connection
- 3.1 Connection instructions
- 3.2 Wiring plan
- 4 Set-up
- 4.1 General adjustment
- 4.2 Level detection
- 4.3 Continuous level measurement
- 5 Diagnosis
- 5.1 Simulation
- 5.2 Maintenance
- 5.3 Repair
- 5.4 Failure removal
Capacitive electrodes EK with signal conditioning instrument 9
For Ex-applications note the permissible
electrical connection values stated in the
certificate.
Product description
Supply
voltage in V
Load in W
Accessory
Straining spring of 1.4571 (EK 42, EK 52, EK 53)
- load approx. 185 mm (stressed)
- tensile load approx. 200 N
Weight
Basic weight (e.g. EK 24) approx. 0,8 kg
Rod weight ø 6 mm - 0,23 kg/m
ø 10 mm - 0,62 kg/m
Cable weight (EK 31) approx. 40 g/m
