Technical data

ENGINE TECHNICAL DATA V12 ENT

The technical code and serial number are indicated on a plate, which

is located on different parts of the engine, according to the model: fly-

wheel casing, tappet cover, coolant tank.

(*)Net power to the flywheel in compliance with ISO 3046-1. Test

conditions: T 25 °C; atmospheric. pressure 100 kPa; relative humid-

ity 30%.

Code V12 ENT M11/M18

Engine family FVME

Cycle 4-stroke diesel

Number and arrangement

of cylinders 12, 90° V

Bore x stroke 145 x 152 mm

Total displacement 30,100 cm

Air system Supercharged aftercooled

Injection type DirectCommon rail, electronically

managed

Engine direction of rotation Anticlockwise (seen from flywheel

side)

Dry weight 2900 kg

Electrical system 24 V

Accumulator/s

capacity

discharge current

330 Ah or above

1800 A or above

Available settings (*) V12 ENT M18

A1 1325 kW (1800 CV) @ 2300 rpm

A2 1201 kW (1632 CV) @ 2300 rpm

B 1152 kW (1565 CV) @ 2200 rpm

C 1001 kW (1360 CV) @ 2100 rpm

Available settings (*) V12 ENT M11

C 956 kW (1300 CV) @ 1800 rpm

D 846 kW (1150 CV) @ 1800 rpm

WARNING

Any alteration of the above mentioned characteristics, in particular

modification of the data stored in the injection system electronic units

or the characteristics of the engine and its fittings, is strictly prohibited,

penalty invalidation of the guarantee and absence of all liability on the

part of IVECO MOTORS.
