Technical data

ENGINE TECHNICAL DATA V08 ENT

The technical code and serial number are indicated on a plate, which

is located on different parts of the engine, according to the model: fly-

wheel casing, tappet cover, coolant tank.

(*)Net power to the flywheel in compliance with ISO 3046-1. Test

conditions: T 25 °C; atmospheric. pressure 100 kPa; relative humid-

ity 30%.

Code V08 ENT M75/M11/M12

Engine family FVME

Cycle 4-stroke diesel

Number and arrangement

of cylinders 8, 90° V

Bore x stroke 145 x 152 mm

Total displacement 20,080 cm

Air system Supercharged aftercooled

Injection type DirectCommon rail,

electronically managed

Engine direction of rotation Anticlockwise (seen from flywheel

side)

Dry weight 1980 kg

Electrical system 24 V

Accumulator/s

capacity

discharge current

260 Ah or above

1500 A or above

Available settings (*) V08 ENT M12

A1 883 kW (1200 CV) @ 2300 rpm

A2 810 kW (1100 CV) @ 2300 rpm

Available settings (*) V08 ENT M11

A2 810 kW (1100 CV) @ 2300 rpm

B 750 kW (1020 CV) @ 2200 rpm

C 635 kW (863 CV) @ 2100 rpm

Available settings (*) V08 ENT M75

C 600 kW (816 CV) @ 1800 rpm

D 551 kW (750 CV) @ 1800 rpm

WARNING

Any alteration of the above mentioned characteristics, in particular

modification of the data stored in the injection system electronic units

or the characteristics of the engine and its fittings, is strictly prohibited,

penalty invalidation of the guarantee and absence of all liability on the

part of IVECO MOTORS.
