CONTROL PANEL OPERATING REQUIREMENTS
The following information refers to IVECO MOTORS equipment in its original configuration.
The requirements and technical characteristics of customised equipment may differ from those set out here, and specific information must be pro-
vided by those responsible for preparing it.
(*) min. 9 V/max. 16 V with reference to equipment for which a rated power supply of 12 V only is foreseen.
IVECO MOTORS on-board control panels With analogue instruments With digital instruments
Operating conditions
Operating temperature range from -10°C to +60°C from -10°C to +60°C
Temperature limits when moored min. -20°C / max. +75°C min. -20°C / max. +75°C
Level of protection from dust and rain (front) IP 65 – DIN 40050 – IEC 529 IP 66
Resistance to brine (Reference Standards) IEC 60068-2-52 IEC 60068-2-52
Electrical and electromagnetic characteristics
Operating voltage (excluding changes in polarity) min. 9 V / max. 32 V (*) min. 9 V / max. 32 V (*)
Maximum over voltage allowed 60 V for 1 ms 60 V for 1 ms
Maximum current absorption in main control panel 1.1 A (12 V) – 1 A (24 V) 310 mA (12 V) – 200 mA (24 V)
Maximum current absorption in secondary control panel 400 mA (12 V) – 400 mA (24 V) 310 mA (12 V) – 200 mA (24 V)
Electromagnetic compatibility (Reference Standards) IEC 945 IEC 945
Electrical connector requirements (Reference Standards) MIL 1344/1001 MIL 1344/1001
Wiring requirements (Reference Standards)
Mechanical characteristics
Resistance to vibration (expressed at gravity acceleration) 1 g eff. max. -25-500 Hz 2 g eff. max. -25-500 Hz
Resistance to impact (expressed at gravity acceleration) 15 g - 1.5 ms - semisinusoidal wave 15 g - 1.5 ms - semisinusoidal wave
CEI 20/22 - CEI 20/38 - CEI 2000/532/CE
