Technical data

30
 Bleed the circuit and top-up if necessary, as indicated in the section
INDICATIONS FOR INITIAL START-UP.
Changing oil vapour filter
Only proceed with the engine stopped and at a low temperature, so
as to avoid the risk of burning. To change both filters, the operations
described below must be repeated on both sides of the oil vapour fil-
ter support.
 Unfasten the screws and remove the cover (1) to the filter com-
partment.
 Remove the filter (2), and dispose of it according to current re-
quirements.
 Insert the new filter and relevant gasket, taking care that it is fitted
the right way round, i.e. with the metal reinforcements (3) facing
outwards.
 Replace the cover and the gasket on the filter housing.
05_021_V
1
2
CAUTION!
The filter (2) only filters effectively in one direction, and it
must be fitted into its housing with the two metal reinforce-
ments (3) facing out, as shown in the figure.
3
1
2
05_122_V
