Technical data

26
 Open the tap (4) and press and hold button A on the electronic
module in the DISCHARGE position, until the sump has emptied
completely.
 Fill up with fresh oil through the feeder hole (2), taking care to use
the types and amounts of oil indicated in the table REFUELLING.
When you finish, fasten the feeder hold cap firmly.
 Using the dipstick (1), check that the oil level is between the "Min"
and "Max" levels.
 Close the drainage tap (4).
 Dispose of used oil according to current requirements.
Changing oil filters
Only use filters with a filtration level equivalent to the ones you are
replacing (or as indicated in the secion FREQUENCY).
Only proceed with the engine stopped and at a low temperature, so
as to avoid the risk of burning, and preferably after having drained the
used oil.
 Place a container under the filter support (3, figure on this page) to
collect the used oil.
 Unscrew and remove the filters.
 Carefully clean the surfaces that are in contact with the gaskets.
 Damp the new filter seals with a thin layer of oil.
 Hand screw the new filters into place until the seal gasket touches
the support, then lock by a further 3/4 of a turn.
 Dispose of the used filters according to current requirements.
#(!2'%
$)3#(!2'%
04_036_C
A
4
05_008_V
3
2 1
WARNING
When replacing the filters, make certain that no oil comes into contact
with the alternator drive belt.
