Checking corrosion of zinc anodes
Only proceed with the engine stopped and at a low temperature:
 Provide suitable containers to ensure that no water is dispersed in-
side the vessel during removal of the anodes.
 Remove the anodes (1), unscrewing them from their housings (see
location in the section ENGINE TECHNICAL DATA).
 Make sure that corrosion has not exceeded 50% of the volume of
zinc. If this is the case, change them.
 Replace the anodes in their housings, changing the seal gaskets.
Changing engine oil
Only proceed with the engine stopped and at a low temperature, so
as to avoid the risk of burning.
The oil is extracted with the aid of the electric pump, controlled using
the button on the relevant electronic module control panel; for safety
reasons the operation is only possible with the start/stop key switch in
position 8A (stop).
 Connect the system drainage tap to a container to collect the used
oil.
1
05_008_V
1
05_020_V
05_008_V
1
