User's Manual
Table Of Contents
- Contents
- Contents v
- Figures ix
- Tables xi
- Preface xv
- Appendix A Specifications 157
- Appendix B Factory Configuration 159
- Appendix C CommandLine Syntax 163
- Appendix D Antenna Guidelines 181
- Appendix E CCU/EUM Data Tables 183
- Appendix F Ping Commands 197
- Appendix G SNMP MIB Definitions 199
- Appendix H Operating Statistics 223
- Appendix I IP Plan — Example 241
- Appendix J Acronyms and Glossary 253
- Index 261
- Figures
- Tables
- Preface
- 1 Introduction
- 2 Quick Startup
- 3 Detailed Description
- 4 IP Network Planning
- 5 Radio Network Planning
- 6 Installation/Diagnostic Tools
- 7 Configuring the CCU
- 7.1 CCU and EUM Serial Number, MAC Address, and Station ID
- 7.2 Setting the CCU Password
- 7.3 Configuring the CCU RF Parameters
- 7.4 Configuring CCU IP Parameters
- 7.5 Configuring DHCP Relay
- 7.6 Configuring Port Filtering
- 7.7 Configuring the SNTP/UTC Time Clock
- 7.8 Configuring SNMP
- 7.9 Adding EUMs to the Authorization Table
- 8 Configuring the EUM
- 9 Installing the EUM
- 9.1 Before you Start the EUM Installation
- 9.2 Other EUM Programming Considerations
- 9.3 Installation Overview
- 9.4 Installation Procedures
- 9.4.1 Opening the Box
- 9.4.2 Turning off the End-user’s Cordless Phones
- 9.4.3 Choosing a Location for the EUM and Antenna
- 9.4.4 Connecting the EUM Components
- 9.4.5 Conducting a Preliminary Check of the EUM
- 9.4.6 Positioning the Antenna
- 9.4.7 Mounting the Antenna
- 9.4.8 Connecting the End-user’s PC
- 9.4.9 Obtaining Valid IP Addresses for the End-user’s PC
- 9.4.10 Testing the Data Link
- 9.4.11 Configuring the Browser Application
- 9.4.12 Completing the Installation
- 9.4.13 Baselining the Installation
- 9.4.14 Troubleshooting
- 10 Maintaining the Network
- 11 Monitoring the Network
- 12 Troubleshooting
- 13 Specialized Applications
- Appendix A Specifications
- Appendix B Factory Configuration
- Appendix C CommandLine Syntax
- Appendix D Antenna Guidelines
- Appendix E CCU/EUM Data Tables
- Appendix F Ping Commands
- Appendix G SNMP MIB Definitions
- MIB-II Elements Supported from RFC-1213
- WaveRider CCU Enterprise MIBs
- CCU Base MIB
- CCU General Information Group
- CCU Radio Configuration Group
- CCU Radio Statistics Group
- CCU Radio General Statistics Group
- CCU Radio Driver Statistics Group
- CCU Radio MAC Statistics Group
- CCU Ethernet Statistics Group
- CCU Modem Information MIB
- CCU Registration Information MIB
- CCU Registration Table
- CCU Authorization Information MIB
- CCU Authorization Table
- CCU RFC MIB-II Traps
- WaveRider EUM Enterprise MIBs
- EUM RFC MIB-II Traps
- Appendix H Operating Statistics
- Appendix I IP Plan — Example
- Appendix J Acronyms and Glossary
- Index
3 Detailed Description
18 APCD-LM043-4.0
settings as the failed CCU. In this way, the CAP can be provisioned for N+1 redundancy,
meaning there is one backup CCU for ‘N’ operating CCUs, up to a maximum of N=3.
Figure 10 RFSM
RF Distribution Panel
The optional RF Distribution Panel provides
• external interface to the antenna subsystem and site ground,
• common surge protector mounting point for each external RF interface, and
• common ground point for all CAP components.
Other Optional CAP Equipment
Depending on your configuration and operational requirements, you may require other
components in your LMS4000 CAP, such as a UPS system, CCU Shelf, or free-standing
19–inch rack.
The CCU Shelf is a standard 19-inch mounting rack with an integrated power supply fan and
cooling fans. It contains five CCU slots, for up to three operating CCUs, a backup CCU, and
backhaul CCU.
These optional components can be ordered through WaveRider.
3.3 Customer-premises Equipment
3.3.1 Key Components
The following Customer-premises Equipment components are key:
•EUM
• EUM antenna
• Transmission line
• Lightning arrestor
