2 Quick Startup
12 APCD-LM043-4.0
4. Select Use the following DNS server address (the exact wording depends on your
operating system), and enter the IP address for the Preferred DNS Server, which is
available from your Network Administrator.
5. Connect the CCU Ethernet port to the appropriate network switch or hub, or directly to
the gateway router of your network.
6. From the PC, you should now be able to open your browser and surf the Web.
2.7 Adding more EUMs to the Quick Startup
You can add other EUMs and PCs to the Quick Startup system. At all times, try to maintain at
least 3 to 5 m (10 to 15 ft.) separation between the EUMs, and between the EUMs and the
CCU.
Other EUMs are added in the same way as the first EUM, using the same gateway IP address
(10.0.0.1), subnet masks (255.255.252.0), and the following EUM and PC IP addresses:
Table 2 Quick Startup — EUM Addresses
EUM
Number
EUM IP Address PC IP Address
2 10.0.0.3 10.0.1.3
3 10.0.0.4 10.0.1.4
4 10.0.0.5 10.0.1.5
5 10.0.0.6 10.0.1.6
6 10.0.0.7 10.0.1.7
