APCD-LM043-4.0 247
CAP10 CCU01 EUM001-253 172.16.112.2 - 172.16.112.254
EUM254-300 172.16.113.1 - 172.16.113.47
CCU02 EUM001-253 172.16.116.2 - 172.16.116.254
EUM254-300 172.16.117.1 - 172.16.117.47
CCU03 EUM001-253 172.16.120.2 - 172.16.120.254
EUM254-300 172.16.121.1 - 172.16.121.47
CAP11 CCU01 EUM001-253 172.16.124.2 - 172.16.124.254
EUM254-300 172.16.125.1 - 172.16.125.47
CCU02 EUM001-253 172.16.128.2 - 172.16.128.254
EUM254-300 172.16.129.1 - 172.16.129.47
CCU03 EUM001-253 172.16.132.2 - 172.16.132.254
EUM254-300 172.16.133.1 - 172.16.133.47
CAP12 CCU01 EUM001-253 172.16.136.2 - 172.16.136.254
EUM254-300 172.16.137.1 - 172.16.137.47
CCU02 EUM001-253 172.16.140.2 - 172.16.140.254
EUM254-300 172.16.141.1 - 172.16.141.47
CCU03 EUM001-253 172.16.144.2 - 172.16.144.254
EUM254-300 172.16.145.1 - 172.16.145.47
CAP13 CCU01 EUM001-253 172.16.148.2 - 172.16.148.254
EUM254-300 172.16.149.1 - 172.16.149.47
CCU02 EUM001-253 172.16.152.2 - 172.16.152.254
EUM254-300 172.16.153.1 - 172.16.153.47
CCU03 EUM001-253 172.16.156.2 - 172.16.156.254
EUM254-300 172.16.157.1 - 172.16.157.47
CAP14 CCU01 EUM001-253 172.16.160.2 - 172.16.160.254
EUM254-300 172.16.161.1 - 172.16.161.47
CCU02 EUM001-253 172.16.164.2 - 172.16.164.254
EUM254-300 172.16.165.1 - 172.16.165.47
CCU03 EUM001-253 172.16.168.2 - 172.16.168.254
EUM254-300 172.16.169.1 - 172.16.169.47
Site CCU Subnet ID EUM IP Address Range
