APCD-LM043-4.0 243

CCU Radio IP Addressing Plan

Table 94 Example - CCU Radio Subnet Data

Table 95 Example - CCU Radio IP Addressing Plan

Subnet 172.16.0.0

Subnet Mask Bits 22

Subnet Mask 255.255.252.0 (ff.ff.fc.00)

Site CCU Subnet

CCU Radio

IP Address

CCU Radio Subnet Range Broadcast

CAP01 CCU01 172.16.4.0 172.16.4.1 172.16.4.1 - 172.16.7.254 172.16.7.255

CCU02 172.16.8.0 172.16.8.1 172.16.8.1 - 172.16.11.254 172.16.11.255

CCU03 172.16.12.0 172.16.12.1 172.16.12.1 - 172.16.15.254 172.16.15.255

CAP02 CCU01 172.16.16.0 172.16.16.1 172.16.16.1 - 172.16.19.254 172.16.19.255

CCU02 172.16.20.0 172.16.20.1 172.16.20.1 - 172.16.23.254 172.16.23.255

CCU03 172.16.24.0 172.16.24.1 172.16.24.1 - 172.16.27.254 172.16.27.255

CAP03 CCU01 172.16.28.0 172.16.28.1 172.16.28.1 - 172.16.31.254 172.16.31.255

CCU02 172.16.32.0 172.16.32.1 172.16.32.1 - 172.16.35.254 172.16.35.255

CCU03 172.16.36.0 172.16.36.1 172.16.36.1 - 172.16.39.254 172.16.39.255

CAP04 CCU01 172.16.40.0 172.16.40.1 172.16.40.1 - 172.16.43.254 172.16.43.255

CCU02 172.16.44.0 172.16.44.1 172.16.44.1 - 172.16.47.254 172.16.47.255

CCU03 172.16.48.0 172.16.48.1 172.16.48.1 - 172.16.51.254 172.16.51.255

CAP05 CCU01 172.16.52.0 172.16.52.1 172.16.52.1 - 172.16.55.254 172.16.55.255

CCU02 172.16.56.0 172.16.56.1 172.16.56.1 - 172.16.59.254 172.16.59.255

CCU03 172.16.60.0 172.16.60.1 172.16.60.1 - 172.16.63.254 172.16.63.255

CAP06 CCU01 172.16.64.0 172.16.64.1 172.16.64.1 - 172.16.67.254 172.16.67.255

CCU02 172.16.68.0 172.16.68.1 172.16.68.1 - 172.16.71.254 172.16.71.255

CCU03 172.16.72.0 172.16.72.1 172.16.72.1 - 172.16.75.254 172.16.75.255

CAP07 CCU01 172.16.76.0 172.16.76.1 172.16.76.1 - 172.16.79.254 172.16.79.255

CCU02 172.16.80.0 172.16.80.1 172.16.80.1 - 172.16.83.254 172.16.83.255

CCU03 172.16.84.0 172.16.84.1 172.16.84.1 - 172.16.87.254 172.16.87.255

CAP08 CCU01 172.16.88.0 172.16.88.1 172.16.88.1 - 172.16.91.254 172.16.91.255

CCU02 172.16.92.0 172.16.92.1 172.16.92.1 - 172.16.95.254 172.16.95.255

CCU03 172.16.96.0 172.16.96.1 172.16.96.1 - 172.16.99.254 172.16.99.255
