236 APCD-LM043-4.0
CCU> stats rp
----------------Routing Protocol Statistics -----------------
Rx Eth Dst - Radio : 0
Rx Eth Dst - To Router : 154396
Rx Eth Err - Mblk (Discard) : 0
Rx Eth Err - Msg Buffer (Discard) : 0
Rx Eth Err - Pkt Size (Discard) : 0
Rx Eth Err - Unknown Ether Type (Discard) : 554
Rx Eth Err - IP Filter (Discard) : 0
Rx Radio Dst - App : 340
Rx Radio Dst - Radio : 1268
Rx Radio Dst - To Router : 129025
Rx Radio Dst - Eth : 0
Rx Radio Err - Mblk (Discard) : 0
Rx Radio Err - Msg Buffer (Discard) : 0
Rx Radio Err - Pkt Size (Discard) : 0
Rx Radio Err - Unknown Ether Type (Discard) : 0
Rx Radio Err - Unknown Msg Type (Discard) : 0
Rx Radio Err - Unreg Request (Discard) : 0
Rx Radio Err - Invalid NetPool (Discard) : 0
Rx Radio Err - Could not Duplicate (Discard) : 0
Rx Radio Err - IP Filter (Discard) : 0
Tx Dst - Eth : 131288
Tx Dst - Radio : 136286
Tx Err - Mblk (Discard) : 0
Tx Err - Msg Buffer (Discard) : 0
Tx Err - Pkt Size (Discard) : 0
Tx Dst - Unregistered (Discard) : 0
Tx Dst - Unknown (Discard) : 0
CCU>
Network Interface Statistics
Network Interface Statistics, described in Table 88, are generated by the IP-protocol suite
resident on the CCU and EUM.
Network Interface Statistics are not available in the WaveRider MIBs.
Table 89 Network Interface Statistics
To view all network interface statistics:
Statistic Description
ICMP For information on ICMP, and ICMP-related statistics, refer to RFC729.
IP For information on IP, and IP-related statistics, refer to RFC791.
TCP For information on TCP, and TCP-related statistics, refer to RFC793.
UDP For information on UDP, and UDP-related statistics, refer to RFC768.
