To view the Routing Protocol Statistics:
Rx Radio Err - Unknown Msg Type Number of Ethernet frames from the radio port
that were discarded because of an internal
routing error.
Rx Radio Err - Unreg Request Number of Ethernet frames received from the
radio port that were discarded because they
came from an
unregistered EUM. [CCU only]
Rx Radio Err - Invalid NetPool Number of Ethernet frames received from the
radio port that were discarded because of a
specific type of memory allocation error.
Rx Radio Err - Could not Duplicate Number of Ethernet frames received from the
radio port that were discarded because of a
specific type of memory allocation error.
Rx Radio Err - Reflection Number of Ethernet frames received from the
radio port that were discarded because the
source address was on the EUM (split-horizon
rule). [EUM only]
Rx Radio Err - IP Filter Number of port-filtered Ethernet frames from the
radio port.
Tx Dst - Eth Number of Ethernet frames that were transmitted
through the Ethernet port.
Tx Dst - Radio Number of Ethernet frames that were transmitted
through the radio port.
Tx Err - Mblk Number of transmit Ethernet frames that had to
be discarded because of a specific type of
memory allocation error.
Tx Err - Msg Buffer Number of transmit Ethernet frames that had to
be discarded because of a specific type of
memory allocation error.
Tx Err - Pkt Size Number of transmit Ethernet frames that had to
be discarded because the frame was too large or
too small to decode.
Tx Dst - Unregistered Number of transmit Ethernet frames that had to
be discarded because they were for an
unregistered EUM. [CCU only]
Tx Dst - Unknown Number of transmit Ethernet frames that had to
be discarded because the Ethernet address did
not appear in the Address Table.
Tx Err - Invalid NetPool Number of transmit Ethernet frames that had to
be discarded because of a specific type of
memory allocation error. [EUM only]
Tx Err - Could not Duplicate Number of transmit Ethernet frames that had to
be discarded because of a specific type of
memory allocation error. [EUM only]
Statistic Description
